Поз.
Артикул
Описание
230
PLASTIC PIPE RISING PIPE 4X6 MM
230
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
233
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
236
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
239
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
242
SLEEVE LEAK LINE
245
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
245
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
248
HOLLOW SCREW LINE CONNECTION
248
HOLLOW SCREW LINE CONNECTION
248
HOLLOW SCREW HEATING CONNECTION
251
SEAL RING LINE CONNECTION
251
SEAL RING LINE CONNECTION
254
BRACKET COMPRESSED AIR LINES
257
TAPPING SCREW. SHEET METAL SCREW FUEL LINE
260
LOCK FUEL LINE
263
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
263
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINES TO M 16 / 4 MM ,VOSS 232,KAN 33/00 AS OF PRODUCTION BREAKPOINT DATE 01.01.2004
263
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
266
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
266
PLASTIC PIPE AERATION, ORDER BY THE METER
269
BREATHER , Replaced By: A3933280065
269
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
272
FITTING (PARTS KIT),LINE RUPTURE
275
PLASTIC TUBE2X4MM, ORDER BY THE METER
278
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
281
UNION NUT LINE MOUNTING, Replaced By: N000000006521
284
GLAND LINE MOUNTING
287
SLEEVE LINE MOUNTING
290
BRACKET LINE MOUNTING
293
SHEET METAL SCREW REFLECTOR TO BUMPER
296
LOOM TIE LINE MOUNTING 280 MM
296
LOOM TIE LINE MOUNTING
296
LOOM TIE , Replaced By: A3719977090
296
LOOM TIE365 MM
