Поз.
Артикул
Описание
5
CABLE HARNESS MAIN CABLE HARNESS
8
CABLE HARNESS FROM REAR CABLE CONNECTOR TO TAIL LAMP
9
CABLE HARNESS FRAME MOUNTED CABLE HARNESS,001570
9
CABLE HARNESS ,D 027931
11
ELECTRIC CABLE
11
ELECTRIC CABLE FRAME MOUNTED CABLE HARNESS
11
ELECTRIC CABLE FRAME MOUNTED CABLE HARNESS
24
SENDER UNIT ELECTRIC BELT MONITORING INDICATOR,C 082497
24
SENDER UNIT ELECTRIC BELT MONITORING INDICATOR,074754082606
25
MOUNTING PLATE SENSOR
26
SCREW PLUG SOCKET TO FRAME
27
WASHER TRAILER PLUG SOCKET TO BRACKET
28
NUT BRACKET TO SIDE MEMBER
32
SWITCH CLUTCH SWITCH
33
WASHER
35
SWITCH STOP LIGHT
35
SWITCH STOP LIGHT
35
SWITCH , Replaced By: A6965450009
35
SWITCH , Replaced By: A6935457309
35
SWITCH , Replaced By: A6965450009
38
NUT SWITCH
41
BRACKET POS. CABLE,XB209706
41
BRACKET , Replaced By: A3184280240
43
SCREW , Replaced By: N304017010040
43
SCREW LINES TO BRACKET
47
NUT BRACKET TO SIDE MEMBER,XB209706
47
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
CLAMP BRAKE HOSE BRACKET
50
CLAMP LINE MOUNTING
53
SCREW CONTROL UNIT TO BRACKET M 4X12
53
SCREW CABLE TO ALTERNATOR
56
WASHER PLUG SOCKET TO BRACKET
56
WASHER VALVE TO BRACKET,5 602406
59
LOCK WASHER CABLE TO FUSE BOX
62
NUT PUMP TO BRACKET
63
CLAMP PUMP TO BRACKET
65
SCREW GROUND CONNECTION TO WINDOW SILL,B 959934
66
SCREW BRACKET TO FRAME
68
WASHER PLUG SOCKET TO BRACKET
70
NUT
72
SCREW GROUND CABLE
74
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
77
SCREW SIDE MARKER LAMP
77
SCREW STEP SWITCH AM 5X8
80
WASHER FUSE TO FUSE BOX
83
NUT TWO-WAY VALVE TO BRACKET
84
CABLE CONNECTOR 6-POLE
86
SCREW FUEL CONSUMPTION DISPLAY
89
WASHER B 4,3 DIN 9021. WASHER FUEL CONSUMPTION DISPLAY
92
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
95
HEX. NUT M 4 DIN 934-5 S. NUT FUEL CONSUMPTION DISPLAY
98
SCREW CLUTCH TO FLYWHEEL M 8X60
101
WASHER TRAILER PLUG SOCKET TO BRACKET
104
NUT TAIL LAMP TO BRACKET
999
TERMINAL STOP LIGHT SWITCH
999
SWITCH STOP LIGHT SWITCH,D 383712 PLEASE REFER TO SERVICE INFORMATION NO.: 04/03.
