Поз.
Артикул
Описание
12
CAMSHAFT
18
CYLINDRICAL PIN DIFFERENTIAL LOCK
46
THRUST WASHER CAMSHAFT FIXING, 340.930 FROM ENGINE 085456 ONLY APPLICABLE TO ENGINES WITH CAMSHAFT DRIVEN INJECTION TIMING DEVICE
58
SCREW COVER PLATE TO COVER PLATE
64
CLAMP
70
INTAKE VALVE , VALVE SEAT RING A 366 053 35 31 ORDER ADDITIONALLY
70
INTAKE VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 331411YEAR OF MANUFACTURE 1994, Replaced By: A3660501226, +001A3660533531
70
INTAKE VALVE , VALVE SEAT RING A 366 053 35 31 ORDER ADDITIONALLY
82
EXHAUST VALVE , Replaced By: A3660500627
82
EXHAUST VALVE
82
EXHAUST VALVE
94
VALVE SPRING
106
WASHER VALVE SPRING
106
WASHER
118
SPRING RETAINER
130
VALVE COLLET (VALVE CONE HALF)
130
VALVE COLLET
130
VALVE COLLET
142
VALVE TAPPET STANDARD 27.98 MM-27.99 MM
154
PUSH ROD
154
PUSH ROD
166
ROCKER ARM SPINDLE
171
EXPANSION PLUG LATERAL P.T.O. WITH REVERSE SPEED
178
ROCKER ARM WITH BUSHING,LEFT
178
ROCKER ARMNO. 1, NO. 3, NO. 5, NO. 7
178
ROCKER ARM WITH BUSHING,LEFT
190
ROCKER ARM WITH BUSHING,RIGHT
190
ROCKER ARMNO. 2, NO. 4, NO. 6, NO. 8
190
ROCKER ARM WITH BUSHING,RIGHT
202
BUSHINGTO 366 050 05 33,04 34
214
BALL PIN ROCKER ARM
226
NUT
226
NUT , Replaced By: A4229900051
238
ROCKER ARM BRACKET OIL SUPPLY NO.1
250
ROCKER ARM BRACKETNO.2,5,6
262
ROCKER ARM BRACKETNO.3
262
ROCKER ARM BRACKETNO.3,4
274
SPRING LONG,ROCKER ARM SPACING
286
SPRING
298
SPRING
304
HEADLESS SETSCREW PLANET GEAR, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
310
SPACER TUBE
314
OIL PIPE
318
SEAL RING
322
SPRING
328
SCREW ROCKER SHAFT TO CYLINDER HEAD
334
SCREW ROCKER SHAFT TO CYLINDER HEAD
334
SCREW , Replaced By: A0029903804
999
ROCKER ARM BRACKET , Replaced By: A3520550210, +001N000417006001
999
HEXAGON HEAD BOLT. SCREW VALVE TO BRACKET
