Поз.
Артикул
Описание
5
FRONT SPRING 9-LEAF,1B 897069
5
FRONT SPRING
6
FRONT SPRING 5-LEAF
8
SPRING LEAFNO.1,TO 360 320 01 02
9
SPRING LEAFNO.1
11
BUSHING
11
BUSHING
14
SPRING LEAFNO.2,D 096411
14
SPRING LEAFNO.2,TO 360 320 01 02
15
SPRING LEAFNO.2
17
SPRING LEAFNO.3,1B 897069
17
SPRING LEAFNO.3,4 338246
18
SPRING LEAFNO.3
20
SPRING LEAFNO.4,4 338246
21
SPRING LEAFNO.4
23
SPRING LEAFNO.5,TO 360 320 01 02
26
SPRING LEAFNO.6,D 096411
26
SPRING LEAFNO.6,TO 360 320 01 02
29
SPRING LEAFNO.7,TO 360 320 01 02
32
SPRING LEAFNO.8,TO 360 320 01 02
35
SPRING LEAFNO.9,TO 360 320 01 02
36
SPACER
38
SPACER TUBE , Replaced By: A0003213253
38
SPACER TUBE , Replaced By: A0003213253
41
SCREW SPRING CLAMP TO SPRING LEAF NO.3,6
41
SCREW SPRING CLAMP TO SPRING LEAF NO.4,NO.7,M 8X95
44
NUT LEVER TO SHIFTING SHAFT
44
NUT POWER CYLINDER TO BRACKET
47
SHIM
48
SPACER130X70X22 MM,1B 944529
49
SPACER
50
SPRING BOLT
50
SPRING BOLTM 12X140
51
SPRING BOLT
53
NUT BRACKET TO SIDE MEMBER
53
NUT SPRING BOLT
54
NUT SUPPORT TO SIDE MEMBER
56
RUBBER BUFFER FRONT SPRINGS TO FRONT AXLE
59
PLATE FRONT SPRINGS TO FRONT AXLE
59
PLATE FRONT SPRINGS TO FRONT AXLE
59
PLATE FRONT SPRINGS TO FRONT AXLE
62
U-BOLT FRONT SPRINGS TO FRONT AXLE M18X1,5X250 MM
62
U-BOLT FRONT SPRINGS TO FRONT AXLE M18X1,5X210 MM
65
DOWEL PIN FRONT SPRINGS TO FRONT AXLE 31 MM
65
DOWEL PIN (CENTERING CONE),5 361887, Replaced By: A9303230574
68
SHIM FRONT SPRINGS TO FRONT AXLE,1B 897069
68
SPACER FRONT SPRINGS TO FRONT AXLE
71
NUT STEERING SUPPORT TO FRAME
74
SHACKLE FRONT SPRING SUSPENSION,REAR
77
BUSHING
77
BUSHING
80
SHACKLE PIN FRONT SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
83
GREASE NIPPLE PROTECTIVE TUBE
89
WASHER AS REQUIRED
89
WASHER AS REQUIRED 4.00 MM
89
WASHER AS REQUIRED 4.2 MM
89
WASHER AS REQUIRED 4.20 MM
92
SEAL RING SPRING SUSPENSION
95
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
98
WASHER GROUND CABLE
101
NUT BRACKET TO SIDE MEMBER,XB209706
999
SPRING LEAFNO.1,D 096411
