Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE WABCO,D 227053
5
BRAKE VALVE SERVICE BRAKE KNORR,D 227053
6
REPAIR KIT LARGE SCOPE TO 695 431 71 04
6
REPAIR KIT SMALL SCOPE TO 695 431 74 04
7
GASKET KIT TWO-CIRCUIT BRAKE VALVE TO 002 431 87 05
8
SCREW. UNION SCREW LINE CONNECTION
8
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
11
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
14
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
17
FLANGE SERVICE BRAKE VALVE,D 227053
18
HOSE HAND BRAKE VALVE
19
HOSE HAND BRAKE VALVE
20
SCREW SERVICE BRAKE VALVE,D 227053
20
HEXALOBULAR BOLT
23
NUT HORN TO BRACKET M8
27
T-FITTING BETWEEN THE LINES
28
MUFFLER VALVE BLEEDING
29
SEALING CORD SUCTION LINE TO OIL PUMP
30
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
30
HOSE PRESSURE REGULATOR,CONNECTION: "3"
31
CLAMP , Replaced By: N000000000667
31
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
32
CLAMP , Replaced By: N000000000667
33
VALVE (RELAY VALVE) KNORR
33
VALVE (RELAY VALVE)
34
REPAIR KIT. VALVE REPAIR KIT TO 695 429 71 44
34
REPAIR KITTO 386 429 70 44
35
SCREW. UNION SCREW LINE CONNECTION
35
SCREW. UNION SCREW , Replaced By: A0009973734
36
LOCK , Replaced By: A0009945448
36
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
38
SEAL RING , Replaced By: A0009940747
38
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
41
SCREW PLUG AT TANK
44
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
44
THRUST RING CHECK VALVE TO AIR RESERVOIR
47
O-RING CHECK VALVE TO AIR RESERVOIR
50
BRACKET RELAY VALVE
63
NUT HORN TO BRACKET M8
