Поз.
Артикул
Описание
8
AIR CLEANER"MANN" - MATERIAL PLASTICO,D 159023
8
AIR CLEANER
17
FILTER ELEMENT SAFETY CARTRIDGE
23
FILTER ELEMENT
38
41
COVERTO 376 090 47 01
47
VALVE
48
86
VACUUM BOXTO 376 090 47 01,D 159023
92
HOSETO 376 090 47 01,D 159023
128
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
140
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
143
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
146
SCREW , Replaced By: N910105010017
155
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
155
SCREW BRACKET TO CAB REAR PANEL M 8X20
155
SCREW BRACKET TO SIDE MEMBER M10X35
161
NUT HORN TO BRACKET M8
167
BRACKET VACUUM INDICATOR,AIR CLEANER
173
NUT HORN TO BRACKET M8
173
NUT BRACKET TO FIRE WALL
176
CLAMP COMPRESSED AIR LINE
176
LOOM TIE LINE MOUNTING
176
LOOM TIE ELECTRIC CABLE MOUNTING
