Поз.
Артикул
Описание
5
STEERING BRACKET
5
STEERING BRACKET ,PB988879
8
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X30
11
SCREW SUPPORT TO FRAME M12X1,5X35,D 127794
14
NUT BRACKET TO SIDE MEMBER M12X1.5
15
SCREW STEERING TO STEERING BRACKET
17
PITMAN ARM , USED WITH AIR BRAKE607674
20
DRAG LINK FRONT NAKATA, USED WITH AIR BRAKE
32
DUST CAP SCREWED PART OF JOINT TO 682 460 31 05,98 05,75 05,77 05
35
NUT
38
COTTER PIN
41
STEERING INTERMEDIATE ARM , USED WITH AIR BRAKE
44
GREASE NIPPLE
47
TAPERED ROLLER BEARING FRONT
50
TAPERED ROLLER BEARING INTERMEDIATE LEVER TO BEARING BRACKET
53
SEAL RING
53
SEAL RING
59
TRUNNION BEARING
68
SCREW SUPPORT TO FRAME M12X1,5X35,D 127794
71
NUT BRACKET TO SIDE MEMBER M12X1.5
74
THRUST WASHER STEERING INTERMEDIATE ARM BEARING
77
NUT
80
COTTER PIN
83
CAP AT STEERING INTERMEDIATE ARM
86
DRAG LINK REAR NAKATA, USED WITH AIR BRAKE607674
89
DUST CAPTO 345 460 81 05,376 460 01 05
92
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
95
CLAMPING RINGTO 345 460 86 05
101
JOINT
104
DUST CAPTO 345 460 81 05,376 460 01 05
107
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
110
CLAMPING RINGTO 345 460 86 05
113
CLAMP JOINT TO DRAG LINK
116
SCREW CLAMP TO DRAG LINK M12X1.5X60,TO 682 460 31 05
119
NUT ALTERNATOR TO SUPPORT
125
NUT
128
COTTER PIN
