Поз.
Артикул
Описание
8
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
8
HOLLOW SCREW FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTION: "1"
11
HOLLOW SCREW HEATING CONNECTION
14
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
17
HOLLOW SCREW LINE CONNECTION
20
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
23
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
23
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
27
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
27
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
32
SLEEVE LEAK LINE
40
GLAND , Replaced By: A0019901667
48
UNION NUT
52
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
56
VALVE (THREE-WAY SOLENOID VALVE),047699 NO.8650I.......I I I II .......INO.9985I I I II I
56
VALVE (THREE-WAY SOLENOID VALVE), NO.8650I.......I I I II .......INO.9985I I I II I
59
VALVE 3/2-WAY VALVE
59
VALVE 3/2-WAY VALVE
62
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
65
SHIM THREE-WAY VALVE,047699 NO.8650I.......I I I II .......INO.9985I I I II I
65
SHIM THREE-WAY VALVE,047698 NO.8650I.......I I I II .......INO.9985I I I II I
68
HOLLOW SCREW LINE CONNECTION
71
SEAL RING , Replaced By: N007603010110
74
BRACKET 3/2-WAY VALVE
77
SCREW BRACKET TO LEFT SIDE MEMBER
80
SCREW 3/2-WAY VALVE TO BRACKET M8X55
83
WASHER TRAILER PLUG SOCKET TO BRACKET
86
NUT BRACKET TO SIDE MEMBER
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
92
HOLLOW SCREW HEATING CONNECTION
95
SEAL RING LINE CONNECTION
98
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
101
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
101
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
104
WASHER , Replaced By: A3609902340
107
LOOM TIE
107
LOOM TIE LINE MOUNTING
107
LOOM TIE
110
GUIDE SIGN P.T.O.
999
VALVE
