Поз.
Артикул
Описание
5
BEARING BRACKET BRAKE PEDAL
5
BEARING BRACKET , Replaced By: A6882947001
8
STUD
11
BEARING BRACKET BRAKE PEDAL
11
BEARING BRACKET , Replaced By: A3842947201
14
BRACKET SERVICE BRAKE VALVE
14
BRACKET SERVICE BRAKE VALVE
17
SCREW. STUDM 8X25 MM
17
STUD COVER TO SHIFT CASE
20
GASKET BEARING BRACKET TO CAB
20
GASKET , Replaced By: A6452940280
23
GASKET BEARING BRACKET TO CAB
26
GASKET BRAKE BOOSTER ASSEMBLY TO FIRE WALL
29
SPRING WASHER BRAKE SHOE WITH LINING
32
NUT BATTERY CASE
35
STOP CLUTCH PEDAL
41
STOP CLUTCH PEDAL STOP
44
NUT LEVER TO SHIFTING SHAFT
47
SCREW CLAMP TO BRACKET
50
NUT , Replaced By: N913004006001
53
STOP
53
STOP BRAKE PEDAL
56
PEDAL (CLUTCH PEDAL)
59
NEEDLE BEARING CLUTCH PEDAL
62
PIN CLUTCH PEDAL39 MM(M10) TO A6952907216
65
NUT AIR CLEANER ELEMENT
71
PEDAL BRAKE, NO.8650I.......I I I II .......INO.9985I I I II I
74
BUSHING , Replaced By: A1242920050
77
PAD , Replaced By: A1072910182
80
PIN CLUTCH PEDAL TO BEARING BRACKET
83
PIN CLUTCH PEDAL TO BEARING BRACKET
83
PIN , Replaced By: A6452940074
86
WASHER CLUTCH PEDAL TO BEARING BRACKET
89
SPACER WASHER BRAKE PEDAL TO BEARING BRACKET
92
SPRING BRAKE PEDAL TO BEARING BRACKET
95
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
98
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
101
SCREWM 6X12
104
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
107
WASHER PLUG SOCKET TO BRACKET
110
ROD , Replaced By: A3822908419
110
BEARING BRACKET
113
NUT GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER
116
SPRING RETAINER SPRING TO PUSH ROD
119
SPRING CLUTCH PEDAL RESET,B 974884
122
SPRING RETAINER SPRING TO PUSH ROD
125
CLIP SPRING TO PUSH ROD
128
SPRING PARTS KIT
134
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
137
WASHER BRACKET TO FENDER BRACKET
140
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
145
LOCK RING PUSH ROD TO PEDAL
148
COTTER PIN
