Поз.
Артикул
Описание
5
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
10
HOLLOW SCREW FITTING CONSTANT THROTTLE 3/2-WAY VALVE, CONNECTION: "25"
10
HOLLOW SCREW FITTING COMPRESSED AIR LINE TO OPERATING CYLINDER
15
HOSE , Replaced By: A3885907424
20
TIRE INFLATOR
20
TIRE INFLATOR , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6935900024
20
TIRE INFLATOR
20
TIRE INFLATOR
20
TIRE INFLATOR
25
TEST CONNECTION
25
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
25
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
25
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
30
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
35
WASHER SUPPORT TO FRAME,D 127794
45
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
50
UNION NUT
55
GLAND , Replaced By: A0019901667
60
SLEEVE LEAK LINE
70
GROMMET FOR PASSAGE OF LINE, UP TO IDENT NO. 5 033766,ALSO INSTALLED ON 5 039977
75
LOOM TIE ELECTRIC CABLE MOUNTING
75
LOOM TIE , Replaced By: A3459977390
999
LINE COMPRESSED AIR LINE
999
LINE COMPRESSED AIR LINE
999
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
