Поз.
Артикул
Описание
5
TANK OIL
8
OIL DIPSTICK
8
OIL DIPSTICK , Replaced By: A0004661167
11
FILLER CAP
14
SEAL RING
17
BRACKET
20
FILTER
23
STRAP OIL TANK
26
SCREW , Replaced By: N304017010040
29
BRACKET OIL TANK
32
SCREW BRACKET TO BUMPER,LEFT M 10X25
35
SCREW , Replaced By: N304017010002
38
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
38
HOSE , Replaced By: A3849977482
38
HOSE FROM OIL TANK TO POWER STEERING PUMP AT ENGINE
41
CLAMP , Replaced By: N000000000667
41
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK
41
CLAMP HOSE TO OIL TANK AND TO SUCTION LINE
41
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
44
LINE FROM HOSE TO POWER STEERING PUMP
47
UNION NUT LINE CONNECTION, Replaced By: N000000006243
50
GLAND , Replaced By: A0019901267
53
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
56
SEAL RING LINE TO OIL PUMP
59
SCREW-IN FITTING OIL LINE CONNECTION
59
FITTING DELIVERY LINE TO PUMP
62
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
65
68
UNION NUT LINE CONNECTION, Replaced By: N000000006239
71
GLAND , Replaced By: A0019901967
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
74
HOSE DELIVERY LINE TO PUMP
74
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
77
80
UNION NUT LINE CONNECTION, Replaced By: N000000006239
83
GLAND , Replaced By: A0019901967
86
FITTING DELIVERY LINE TO PUMP
86
SCREW-IN FITTING OIL LINE CONNECTION
89
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
92
SCREW-IN FITTING RETURN LINE TO STEERING
95
SEAL RING SOLENOID VALVE A 18X24
98
101
UNION NUT LINE CONNECTION
104
GLAND LINE CONNECTION
107
HOSE FROM STEERING TO OIL TANK
107
HOSE FROM STEERING TO OIL TANK
110
CLAMP , Replaced By: N000000000667
110
LOOM TIE. CLAMP HOSE TO FLANGE AND TO VALVE
110
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
