Поз.
Артикул
Описание
65
POSITIVE CABLE FROM BATTERY I TO BATTERY II
68
POSITIVE CABLE FROM BATTERY POS.POLE TO STARTING MOTOR
71
BRACKET , Replaced By: A3464296040
74
CLAMP ELECTRIC CABLE TO BRACKET 20/15
74
CLAMP PIPE ON FAN SHROUD
77
SCREW CABLE TO ALTERNATOR
80
WASHER PLUG SOCKET TO BRACKET
86
NUT
89
NEG. CABLE (NEG.CABLE) FROM BATTERY II TO BATTERY CUT-OFF
98
SWITCH BATTERY CUT-OFF
98
SWITCH BATTERY CUT-OFF
101
KEY
104
BRACKET SWITCH TO BATTERY SUPPORT
107
SCREW MODULE TO HOUSING
110
SCREW PUMP TO SIDE MEMBER M 6X35
116
WASHER , Replaced By: N009021006208
119
NUT
122
CONTACTOR STARTING MOTOR,D 090060
122
CONTACTOR , Replaced By: A3885457067
122
CONTACTOR STARTING MOTOR RELAY
125
GASKET
128
BRACKET BATTERY CABLE
131
SCREW BRACKET MOUNTING
134
NUT
137
WASHER FUSE TO FUSE BOX
137
WASHER ACTUATOR TO BRACKET
140
SCREW CROSS MEMBER TO SIDE MEMBERS
143
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
146
GROUND STRAP FROM FRAME TO CAB
149
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER
152
GROUND STRAP FROM FRAME SIDE MEMBER TO CAB
155
SCREW GROUND CABLE
155
SCREW , Replaced By: N304017010040
161
SCREW GROUND CABLE
161
SCREW CROSS MEMBER TO SIDE MEMBERS
164
WASHER GROUND CABLE
167
WASHER GROUND CABLE
170
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
173
BRACKET , Replaced By: A3812950440
173
BRACKET BATTERY CABLE MOUNTING
176
BRACKET POS. CABLE,XB209706
179
BRACKET FUEL LINE
182
SCREW , Replaced By: N304017010040
185
SCREW CROSS MEMBER TO SIDE MEMBERS
188
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
191
CLAMP PIPE ON FAN SHROUD
194
SCREW CABLE TO ALTERNATOR
197
WASHER PLUG SOCKET TO BRACKET
200
NUT
203
CLAMP ENGINE AND FRAME
203
CLAMP ELECTRIC CABLE TO ALTERNATOR 15/12
203
CLAMP ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
203
CLAMP LINE MOUNTING
203
CLAMP ELECTRIC CABLE TO ALTERNATOR 15/12
209
SPRING WASHER CABLE TO ALTERNATOR
212
NUT TACHOGRAPH TO BRACKET
215
CLAMP DELIVERY AND SUCTION LINES TO FRAME
215
CLAMP LINES TO BRACKET
218
NUT COVERING TO CAB FIRE WALL
999
BOTTOM BATTERY SUPPORT
999
SCREW ANGLE TO CROSS MEMBER M 10X30
