Поз.
Артикул
Описание
20
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
57
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
68
LINE12 MM, ORDER BY THE METER4 691315
68
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
68
HOSE TRISTOP CYLINDER,4 412125
68
HOSE TRISTOP CYLINDER,4 412125
71
FITTING HYDRAULIC LINE TO BRACKET,K 130132
71
FITTING HYDRAULIC LINE TO BRACKET,K 130132
71
FITTING HYDRAULIC LINE TO BRACKET,K 130132
74
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
74
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
74
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
156
BRACKET CROSS MEMBER,4 691315
165
BRACKET TRISTOP CYLINDER,4 412126
165
BRACKET TRISTOP CYLINDER,4 412125
167
SCREW PIPE CLAMP
167
SCREW , Replaced By: N304017008021
171
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
171
NUT , Replaced By: N913004008001
174
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
174
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
177
FITTING HYDRAULIC LINE TO BRACKET,K 130132
177
FITTING HYDRAULIC LINE TO BRACKET,K 130132
180
FITTING LINE CONNECTIONS,4 412125
183
ELBOW FITTING ,4 412125
183
ELBOW FITTING ,4 412125
196
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
196
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
196
VALVE TWO-WAY
196
VALVE TWO-WAY
197
VALVE BODYTO 002 429 95 44
197
VALVE , Replaced By: A0004290782
197
VALVE BODYTO 002 429 95 44
197
VALVE , Replaced By: A0004291182
198
BALLTO 003 429 22 44
199
GASKETTO 003 429 22 44
200
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
200
FITTING , Replaced By: A0009970171
200
FITTING , Replaced By: A0019970172
200
FITTING SHUTTLE VALVE
200
FITTING DELIVERY LINE TO PUMP
200
FITTING SHUTTLE VALVE
200
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
200
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
200
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
200
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
200
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
200
FITTING DELIVERY LINE TO PUMP
202
FITTING TWO-WAY VALVE,CONNECTION: "11",4 691316
204
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
204
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
210
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
210
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
212
SEAL RING LINE CONNECTION
213
FITTING TWO-WAY VALVE "12",4 4121264 691315
214
NUT TWO-WAY VALVE "12",4 4121264 691315
216
O-RING CHECK VALVE TO AIR RESERVOIR
222
THRUST RING CHECK VALVE TO AIR RESERVOIR
222
THRUST RING CHECK VALVE TO AIR RESERVOIR
222
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
228
HOLLOW SCREW FUEL LINE TO FEED PUMP
228
HOLLOW SCREW , Replaced By: N915036010108
228
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
228
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
236
SEAL RING FUEL LINE TO FEED PUMP
236
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
236
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
242
FITTING SPRING LOAD ACCUMULATOR CYLINDER,4 412126
242
FITTING LINE CONNECTIONS,4 691315
242
FITTING LINE CONNECTIONS,4 691315
242
FITTING RELAY VALVE,CONNECTION "20",LEFT
242
FITTING RELAY VALVE,CONNECTION "20",LEFT
244
THRUST RING CHECK VALVE TO AIR RESERVOIR
244
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
246
O-RING CHECK VALVE TO AIR RESERVOIR
248
NUT CHECK VALVE TO AIR RESERVOIR
248
NUT CHECK VALVE TO AIR RESERVOIR
250
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
250
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
250
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
254
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
254
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
254
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
254
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
260
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
260
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
260
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
260
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
266
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
266
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
266
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
266
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
270
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
270
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
270
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
270
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
270
FITTING SPRING LOAD ACCUMULATOR CYLINDER,4 4121264 691315
273
SEAL RING LINE CONNECTION
273
SEAL RING LINE CONNECTION
276
HOLLOW SCREW FUEL LINE TO FEED PUMP
276
HOLLOW SCREW , Replaced By: N915036010108
279
SEAL RING FUEL LINE TO FEED PUMP
282
FITTING LINE CONNECTIONS,4 691315
282
FITTING SHUTTLE VALVE
285
SEAL RING LINE CONNECTION
285
SEAL RING FUEL LINE TO FEED PUMP
288
THRUST RING CHECK VALVE TO AIR RESERVOIR
288
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
291
O-RING CHECK VALVE TO AIR RESERVOIR
294
NUT CHECK VALVE TO AIR RESERVOIR
999
BRACKET ,4 273689
999
BRACKET VALVE TO CAB,4 273689
999
NUT TWO-WAY VALVE TO BRACKET
