Поз.
Артикул
Описание
153
STEERING WHEEL , NO.8316INO.7C52INO.7B90INO.9051I II I
156
CAP STEERING WHEEL,4 430199
160
STEERING COLUMN BRACKET
164
NUT STEERING WHEEL TO STEERING COLUMN,4 628576
168
PLUG STEERING COLUMN END,5 0627235 113997
168
PLUG , Replaced By: A3839970286
170
PLUG TOP,5 220080
172
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
176
LOCK WASHER STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET
180
SHELL STEERING COLUMN PANELLING,REAR
180
SHELL STEERING COLUMN PANELLING,REAR
184
SHELL STEERING COLUMN PANELLING,FRONT
184
SHELL STEERING COLUMN PANELLING,FRONT
184
SHELL , Replaced By: A3814622443
188
SCREW STEERING COLUMN PANELLING M 5X75.5,5 227753
192
SCREW STEERING COLUMN PANELLING
196
SCREW
200
LOCK WASHER STEP SWITCH
204
SCREW REAR EXHAUST PIPE TO MUFFLER
208
SPRING WASHER STEERING COLUMN BRACKET TO CAB
212
STEERING SHAFT
212
STEERING SHAFT , Replaced By: A3814607109
214
WASHER
218
SEAL RING
222
SEAL HOLDER
226
SLEEVE STEERING SHAFT
230
UNIVERSAL JOINT , Replaced By: A3164600057, +002A3169900114
234
SCREW STEERING SHAFT TO STEERING M 8X42
238
NUT STRAP TO BRACKET
244
PROTECTIVE SLEEVE PROTECTIVE SLEEVE TO CAB FLOOR
245
SHEET METAL SCREW BOOT TO CAB FLOOR
245
SHEET METAL SCREW , Replaced By: N007981005321
246
GASKET PROTECTIVE SLEEVE TO CAB FLOOR
247
REINFORCEMENT PROTECTIVE SLEEVE TO CAB FLOOR
248
BOOT STEERING COLUMN COVERING,TOP, NO.8316INO.7C52INO.7B90INO.9051I II I
249
WASHER UNIVERSAL JOINT COVERING
252
BOOT UNIVERSAL JOINT COVERING, NO.8316INO.7C52INO.7B90INO.9051I II I
256
STEERING SUPPORT
257
SCREW STEERING SUPPORT TO FRAME M 14X50
257
SCREW , Replaced By: N000960014225
258
NUT CAB ON CONSOLE AT FRAME
259
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
260
PITMAN ARM ,4 298137
264
NUT PITMAN ARM TO STEERING BOX ASSEMBLY,5 386585
264
NUT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 760470 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0029905051
268
DRAG LINKEHRENREICH,5 593344
268
DRAG LINKLEMFOERDER,5 593344
268
DRAG LINK , Replaced By: A3874603505
268
DRAG LINKEHRENREICH,5 593344
268
DRAG LINKLEMFOERDER,5 593344
268
DRAG LINK , Replaced By: A3874603205
268
DRAG LINK , EXHAUST STOCK OF OLD PART NUMBERS FIRST FROM IDENT NO. 4 298137-4 621300, Replaced By: A3874601405
276
BOOT DRAG LINK
280
DRAG LINK END , Replaced By: A0014607748
280
DRAG LINK END , Replaced By: A0014602248
280
DRAG LINK END , Replaced By: A0014601248, +001A0019905451
280
DRAG LINK END , Replaced By: A0014607748
280
DRAG LINK END , Replaced By: A0014602248
280
DRAG LINK END , Replaced By: A0014600848
280
DRAG LINK END , Replaced By: A0004602848
288
BOOT DRAG LINK
288
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0004621796
292
CLAMP CLAMP, TWO-HOLE
296
SCREW CLAMP, TWO-HOLE
300
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
300
NUT , Replaced By: N910113012003
304
NUT DRAG LINK TO LEVER
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
BADGE STEERING WHEEL, NO.8316INO.7C52INO.7B90INO.9051I II I
999
FILTER , Replaced By: A0004660604
999
SEALING CORD , Replaced By: A0059970848
999
NEEDLE BEARING
999
HOSE , Replaced By: A0009978252
999
HOSE , Replaced By: A0009978252
999
PROTECTIVE CAP
999
STEERING WHEEL ,4 430199, Replaced By: A3834640201, +001A0004640432
999
COVER
999
HOSE , Replaced By: A3439970582
999
STEERING SHAFT , USED WITH SHORT MERCEDES-BENZ CAB, Replaced By: A6504600209
999
STEERING COLUMN BRACKET
999
RING STEERING SHAFT
999
WASHER , Replaced By: A3814620475
999
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 456943, Replaced By: A3814621196
999
LINE RETURN, FROM STEERING TO OIL TANK,5 593344
999
LINE FROM HIGH PRESSURE HOSE TO STEERING, 993034
999
LINE FROM HIGH PRESSURE HOSE TO STEERING, 993034
999
BOOT STEERING COLUMN TO CAB, NOT USED
999
STEERING SUPPORT
999
PROTECTIVE SLEEVE UNIVERSAL JOINT COVERING,4 188586
999
PROTECTIVE SLEEVE UNIVERSAL JOINT COVERING,4 188586
999
COVER PROTECTIVE SLEEVE TO CAB FLOOR,4 188586
999
STEERING SHAFTLEMFOERDER, USED WITH SHORT MERCEDES-BENZ CAB
999
STEERING SHAFT , USED WITH SHORT MERCEDES-BENZ CAB
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
WIRE STEERING BOX ASSEMBLY TO STEERING SUPPORT 600 MM
999
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
999
SCREW , Replaced By: N308676012017
999
SCREW STEERING SUPPORT TO FRAME M 14X55
999
SCREW-IN FITTING OIL LINE CONNECTION
999
SHEET METAL SCREW PROTECTIVE SLEEVE TO CAB FLOOR,4 188586
999
NUT STEERING WHEEL TO STEERING COLUMN
999
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
