Поз.
Артикул
Описание
3
CONNECTOR LEFT FRONT
6
CONNECTOR RIGHT FRONT
9
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ELIMINATED - NO LONGER REQUIRED
9
FLANGE GASKET , Replaced By: A4424920080
9
FLANGE GASKET , Replaced By: A3024900080
12
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
15
NUT CONNECTOR TO EXHAUST MANIFOLD
18
CONNECTOR INTERMEDIATE PIECE
21
EXHAUST PIPE LEFT FRONT,4 135870
21
FRONT EXHAUST PIPE , Replaced By: A3874904419
23
EXHAUST PIPE RIGHT FRONT,4 135870
23
FRONT EXHAUST PIPE , Replaced By: A3874904519
33
BRACKET LEFT EXHAUST PIPE
38
CLAMP FRONT EXHAUST PIPE TO BRACKET,5 129244
42
EXHAUST MUFFLER ,4 468224
46
CLAMP BRACKET TO FRONT EXHAUST PIPE
51
BRACKET EXHAUST MUFFLER TO SIDE MEMBER,4 135870
51
BRACKET EXHAUST MUFFLER TO SIDE MEMBER,4 135870
61
BRACKET EXHAUST MUFFLER TO FRAME,960006
71
REAR EXHAUST PIPE
71
REAR EXHAUST PIPE ,4 135870
81
BRACKET REAR EXHAUST PIPE
81
BRACKET REAR EXHAUST PIPE,4 135870
91
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
999
EXHAUST PIPE FRONT RIGHT
999
BRACKET , Replaced By: A3874914041
999
BRACKET , Replaced By: A3874925941
999
BRACKET , Replaced By: A3874926041
999
BRACKET , Replaced By: A3874925941
999
BRACKET , Replaced By: A3874926041
999
BRACKET RIGHT EXHAUST PIPE
999
WASHER
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017008034
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017010002
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW , Replaced By: N308676012015
999
SCREW , Replaced By: N308676012026
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW PIPE CLAMP
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW LEFT AND RIGHT CONSOLES TO CAB
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
NUT STRAP TO BRACKET
999
NUT SUPPORT TO SIDE MEMBER
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
NUT , Replaced By: N910113010000
