Поз.
Артикул
Описание
5
REAR SPRING
5
REAR SPRING
8
SPRING LEAFNO.1
11
BUSHING
11
BUSHING
14
SPRING LEAFNO.2
17
SPRING LEAFNO.3
20
SPRING LEAFNO.4,TO 352 320 04 06
23
SPRING LEAFNO.5,TO 352 320 04 06
26
SPRING LEAFNO.6,TO 352 320 04 06
29
SPRING LEAFNO.7
32
SPRING LEAFNO.8,TO 352 320 04 06
35
SPRING LEAFNO.9,TO 352 320 04 06
38
SPRING LEAFNO.10
41
SPRING LEAFNO.11
44
SPRING BOLT FRONT SPRINGS TO FRONT AXLE
44
SPRING BOLTM 12X195,B 969046
47
NUT , Replaced By: N910113012005
50
SPACER TUBE , Replaced By: A3140720253
53
SCREW
56
NUT SPRING CLAMP
107
PLATE TORSION BAR TO REAR AXLE, 752309
110
JOINT BEARING TORSION BAR TO LINK,5 903513
110
JOINT BEARING TORSION BAR TO LINK,5 903513
113
LOCK RING TORSION BAR TO LINK,5 903513
116
GREASE NIPPLE
116
GREASE NIPPLE
119
U-BOLT REAR SPRING TO REAR AXLE 390 MM
119
U-BOLT REAR SPRING TO REAR AXLE
119
U-BOLT , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE ONLY REPLACEABLE BY PAIRS5 999999K 000001 - K 028584, Replaced By: A6793510625, +001A6793250031
122
WASHER FRONT SPRINGS TO FRONT AXLE
125
NUT
128
PAD REAR SPRING TO REAR AXLE
131
DOWEL PIN FRONT SPRINGS TO FRONT AXLE 38 MM
134
STOP , USED WITH AIR BRAKE,FROM CHASSIS 588186
137
SCREW RUBBER BUFFER TO FRAME
140
HEX. NUT. NUT SHIFT LEVER KNOB
143
SHACKLE REAR SPRING SUSPENSION
146
BUSHING
146
BUSHING
149
SHACKLE PIN REAR SPRING TO SPRING SHACKLE, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
149
SHACKLE PIN REAR SPRING TO REAR SPRING FRONT BRACKET
149
SHACKLE PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3923257130
152
GREASE NIPPLE
155
WASHER AS REQUIRED 4.2 MM
155
WASHER AS REQUIRED 4.0 MM
155
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
155
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
158
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
161
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
164
WASHER , Replaced By: N000125010532
167
NUT BRAKE LEVER TO CONSOLE
