Поз.
Артикул
Описание
8
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
12
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
16
HANDLETO 000 434 23 01
20
CUP 3/2-WAY VALVE WABCO
26
SEAL RINGTO 000 434 23 01
32
SEAL RINGTO 000 434 23 01
38
SEAL RINGTO 000 434 21 01
50
STRAINERTO 000 434 21 01
56
REPAIR KIT 3/2-WAY VALVE WABCO
59
REPAIR KIT 3/2-WAY VALVE BOSCH
62
SPRING WASHER AT CAB FLOOR
68
NUT SUCTION LINE TO OIL PUMP
74
HOLLOW SCREW HEATING CONNECTION
80
SEAL RING LINE CONNECTION
86
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
86
BREATHER , Replaced By: A3933280065
248
DISTRIBUTOR EXHAUST BRAKE VALVE LINE CONNECTION
254
SCREW DISTRIBUTOR TO CAB
260
WASHER COMPRESSED AIR LINE TO BRACKET
266
NUT PUMP TO BRACKET
272
HOLLOW SCREW LINE CONNECTION
278
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
284
SEAL RING LINE CONNECTION
290
FITTING FROM PUMP TO CYLINDER
290
FITTING , Replaced By: A0019909871
290
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
296
FITTING , Replaced By: A0019900170
296
T-FITTING EXHAUST-BRAKE POWER CYLINDER
298
FITTING LINE CONNECTION TO FIRE WALL,5 726664
316
ANGLE LINE MOUNTING
316
ANGLE , Replaced By: A3604280243
318
LOOM TIE
318
LOOM TIE LINE MOUNTING
318
LOOM TIE LINE MOUNTING 280 MM
999
SPRINGTO 000 434 21 01
