Поз.
Артикул
Описание
8
SLOTTED GATE FOR AUTOMATIC TRANSMISSION
8
SLOTTED GATE FOR AUTOMATIC TRANSMISSION
16
SHIFT LEVER
24
SHEET METAL SCREW , Replaced By: N007981004261
32
WIRE CABLE FOR AUTOMATIC TRANSMISSION
40
CLAMPING PIECE WIRE CABLE TO BRACKET
48
CLAMP WIRE CABLE TO BRACKET
56
SCREW , Replaced By: N304017006016
56
SCREW PUMP TO BRACKET
64
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
72
BALL SOCKET AT CONTROL LEVER
80
NUT BALL PIVOT TO LEVER
88
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
96
BRACKET MODULATOR
104
CONSOLE
112
BRACKET
112
BRACKET
120
BRACKET HEATING PIPE
128
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
136
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
136
SCREW , Replaced By: N304017008016
144
LOCK WASHER RAIL TO BATTERY SUPPORT
152
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
152
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
152
CLAMP LINES TO BRACKET
160
SCREW PUMP TO BRACKET
160
SCREW , Replaced By: N304017006020
160
SCREW , Replaced By: N304017006016
160
SCREW , Replaced By: N304017008021
160
SCREW CONSOLE TO SIDE MEMBER
160
SCREW PIPE CLAMP
160
SCREW LICENSE PLATE TO BRACKET
176
SCREWM 12X13X18X35
184
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
184
NUT , Replaced By: N913004008001
184
NUT , Replaced By: N913004006001
184
NUT PUMP TO BRACKET
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
