Поз.
Артикул
Описание
300
PROPELLER SHAFT FROM TRANSMISSION TO PROPELLER SHAFT BEARING
300
PROPELLER SHAFT FROM TRANSMISSION TO PROPELLER SHAFT BEARING
300
PROPELLER SHAFT FROM TRANSMISSION TO PROPELLER SHAFT BEARING
306
PROPELLER SHAFT FROM TRANSMISSION TO VOITH RETARDER
315
CENTERING FLANGE
315
DRIVE FLANGE
315
CENTERING FLANGE
318
UNIVERSAL JOINT CROSS
318
UNIVERSAL JOINT CROSS
321
GREASE NIPPLE
330
GREASE NIPPLE
336
SEAL RING
339
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
339
NUT PROPELLER SHAFT TO COUPLING FLANGE
339
SCREW PROPELLER SHAFT TO REAR AXLES I AND II
345
NUT PROPELLER SHAFT TO REAR AXLES I AND II
345
NUT
345
NUT PROPELLER SHAFT TO REAR AXLES I AND II
400
INTERMEDIATE BEARING , Replaced By: A3854100922
500
PROPELLER SHAFT FROM INTERMEDIATE BEARING TO REAR AXLE
510
PROPELLER SHAFT FROM VOITH RETARDER TO PROPELLER SHAFT BEARING
515
DRIVE FLANGE
515
CENTERING FLANGE
518
UNIVERSAL JOINT CROSS
999
GREASE NIPPLE FOR SPRING
