Поз.
Артикул
Описание
140
PLASTIC PIPE AERATION, ORDER BY THE METER
140
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
142
BANJO UNION HEATING CONNECTION,K 169122
142
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
143
UNION NUT
143
UNION NUT LINE CONNECTION
144
GLAND , Replaced By: A0019901667
144
GLAND LINE CONNECTION
145
SLEEVE LINE CONNECTION
146
FITTING 3/2-WAY VALVE
147
COUPLING FROM CHECK VALVE TO PARKING BRAKE VALVE
148
LOOM TIE LINE MOUNTING
148
LOOM TIE LINE MOUNTING 280 MM
644
VALVE (RELAY VALVE) BOSCH
644
VALVE (RELAY VALVE) GRAU
644
VALVE (RELAY VALVE) KNORR
644
VALVE (RELAY VALVE) WABCO
645
SEAL RING22.3X2.4 MM,GRAU
646
VALVE SEATGRAU
647
SEAL RINGTO 000 429 28 95,GRAU
648
SEAL RING28X2 MM,GRAU
649
SEAL RING86X2 MM,GRAU
650
GASKET34X2X6 MM,GRAU
654
VALVEBOSCH
654
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
654
REPAIR KIT , Replaced By: A0004201071
656
REPAIR KIT , Replaced By: A0004301109
656
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
656
REPAIR KITWABCO
656
REPAIR KITKNORR
660
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
664
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
666
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
668
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
670
O-RING CHECK VALVE TO AIR RESERVOIR
674
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
678
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
680
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
682
WASHER , Replaced By: N000125008443
684
NUT , Replaced By: N913004008001
850
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
850
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0024309981
850
VALVE PARKING BRAKE VALVE KNORR
850
VALVE PARKING BRAKE VALVE BOSCH
851
PROTECTIVE CAPTO WABCO
851
PROTECTIVE CAPTO BOSCH
851
PROTECTIVE CAPKNORR
854
REPAIR KIT , Replaced By: A0034303181
854
REPAIR KITTO 001 430 56 81,001 430 57 81
854
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
854
REPAIR KITTO 002 430 98 81,99 81,KNORR
856
HANDLETO WABCO
856
HANDLEKNORR
857
REPAIR KITTO BOSCH
858
HANDLETO 001 430 34 81,001 430 43 81,BOSCH
862
SCREW PARKING BRAKE VALVE TO WINDOW SILL
864
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
999
SEAL RING BRAKE HOSE
999
GUMMED LABEL PARKING BRAKE ACTUATION
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
