Поз.
Артикул
Описание
5
FRONT SPRING 8-LEAF
5
FRONT SPRING 5-LEAF
5
FRONT SPRING 7-LEAF
5
FRONT SPRING 8-LEAF, ONLY REPLACEABLE BY PAIRS
5
5
FRONT SPRING 8-LEAF, ONLY REPLACEABLE BY PAIRS
5
FRONT SPRING
8
SPRING LEAFNO.1,TO 682 320 73 02
8
SPRING LEAFNO.1,TO 682 320 75 02
8
SPRING LEAFNO.1,TO 360 320 01 02
8
SPRING LEAFNO.1,TO 682 320 72 02
8
SPRING LEAFNO.1
8
SPRING LEAFNO.1,TO 682 320 74 02
11
BUSHING
11
BUSHING
14
SPRING LEAFNO.2, TO 682 320 73 02
14
SPRING LEAFNO.2
14
SPRING LEAFNO.2, TO 682 320 72 02
14
SPRING LEAFNO.2, TO 682 320 74 02
14
SPRING LEAFNO.2,TO 360 320 01 02
14
SPRING LEAFNO.2, TO 682 320 75 02
17
SPRING LEAFNO.3, TO 682 320 73 02
17
SPRING LEAFNO.3,4 338246
17
SPRING LEAFNO.3, TO 682 320 75 02
17
SPRING LEAFNO.3, TO 682 320 72 02
17
17
SPRING LEAFNO.3
20
20
SPRING CLAMP AT LEAF N0.3
23
RIVET
23
RIVET , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
26
SPRING LEAFNO.4, TO 682 320 74 02
26
SPRING LEAFNO.4, TO 682 320 72 02
26
SPRING LEAFNO.4
26
SPRING LEAFNO.4,4 338246
26
SPRING LEAFNO.4, TO 682 320 75 02
26
SPRING LEAFNO.4, TO 682 320 73 02
29
41
RIVET
47
SPRING LEAFNO.5, TO 682 320 75 02
47
47
47
SPRING LEAFNO.5, TO 682 320 73 02
47
SPRING LEAFNO.5,TO 360 320 01 02
47
SPRING LEAFNO.5, TO 682 320 74 02
68
SPRING LEAFNO.6,TO 360 320 01 02
68
71
SPRING CLAMP AT SPRING LEAF NO.6
74
RIVET , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
80
SPRING LEAFNO.7,TO 360 320 01 02
83
SPRING LEAFNO.8,TO 360 320 01 02
83
SPRING LEAFNO.8, TO 682 320 72 02
95
SPRING LEAFNO.9,TO 360 320 01 02
101
SPACER
101
SHIM
101
SPACER130X70X22 MM,1B 944529
101
SPACER
104
SPRING BOLT
104
SPRING BOLTM 12X140
107
NUT STRAP TO SUPPORT
107
NUT SUPPORT TO SIDE MEMBER
107
NUT CONNECTOR TO EXHAUST MANIFOLD
110
SPACER TUBE SPRING CLAMP TO SPRING LEAF NO.5, TO 682 320 73 02
110
SPACER TUBE SPRING CLAMP TO SPRING LEAF,5 484790
110
SPACER TUBE SPRING CLAMP
110
SPACER TUBE , Replaced By: A0003213253
113
SCREW BRACKET TO AIR SPRING BELLOWS SUPPORT
113
SCREW SPRING CLAMP TO SPRING LEAF NO.4,NO.7,M 8X95
113
SCREW FOR SPRING CLAMPS
113
SCREW SPRING CLAMP TO SPRING LEAF NO.3,6
113
SCREW SPRING CLAMP TO SPRING LEAF NO.3, TO 682 320 72 02, M 12X110
116
NUT POWER CYLINDER TO BRACKET
116
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
116
NUT LEVER TO SHIFTING SHAFT
116
NUT STRAP TO SUPPORT
119
SHACKLE FRONT SPRING SUSPENSION,REAR
122
BUSHING
122
BUSHING
125
SHACKLE PIN FRONT SPRING TO SPRING SHACKLE AND TO SPRING REAR BRACKET
128
SEAL RING SPRING SUSPENSION
131
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
134
WASHER GROUND CABLE
137
NUT EXHAUST PIPE TO SIDE MEMBER
137
NUT , Replaced By: N910113010000
140
GREASE NIPPLE
143
GREASE NIPPLE
146
WASHER AS REQUIRED
146
WASHER AS REQUIRED 4.00 MM
146
WASHER AS REQUIRED 4.2 MM
146
WASHER AS REQUIRED 4.20 MM
149
PLATE FRONT SPRINGS TO FRONT AXLE
149
PLATE
149
PLATE
155
HELPER SPRING SPRING STOP TO FRAME BOTTOM SIDE
155
RUBBER BUFFER
161
U-BOLT FRONT SPRINGS TO FRONT AXLE M18X1,5X210 MM
161
U-BOLT FRONT SPRINGS TO FRONT AXLE M18X1,5X190 MM
161
U-BOLT , Replaced By: A3523510425
161
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
176
NUT TORSION BAR TO BEARING BRACKET,5 904661
176
NUT TORSION BAR TO BEARING BRACKET,5 904661
