Поз.
Артикул
Описание
6
BEARING BRACKET HOLE SPACING: 100 MM
9
HOUSING STABILIZER,D 012295
11
RUBBER MOUNTING STABILIZER,D 012295
14
TORSION BAR BODY MOUNTING
17
SPACER RING FRONT AXLE STABILIZER
20
SCREW EXHAUST PIPE TO BRACKET
23
NUT , Replaced By: N910113010000
23
NUT EXHAUST PIPE TO SIDE MEMBER
26
LEVER FRONT AXLE STABILIZER
29
JOINT BEARING , Replaced By: A0009817331
29
JOINT BEARING , Replaced By: A0009817231
29
JOINT BEARING FRONT AXLE STABILIZER
32
SNAP RING FRONT AXLE STABILIZER
35
NUT LEVER TO TORSION BAR
38
COTTER PIN LEVER TO TORSION BAR
41
ROD
41
ROD (ARTICULATED ROD) NAKATA,D 012296
41
ROD LEVER TO TORSION BAR
41
ROD (ARTICULATED ROD) TRW,D 012296
44
NUT M14X1,5 MM
47
COTTER PIN
50
REPAIR KIT
54
SEAL RING ARTICULATED ROD TO LEVER,D 012295
54
SEAL RING ROD TO TORSION BAR
56
PIN ARTICULATED ROD TO LEVER,D 012295
59
SPACER TUBE
62
TOOTHED WASHER ROD TO TORSION BAR
65
TOOTHED WASHER ROD TO TORSION BAR
68
NUT ARTICULATED ROD TO LEVER,D 012295
71
GREASE NIPPLE PROTECTIVE TUBE
74
REPAIR KIT TORSION BAR,FRONT,D 012295
77
SHOCK ABSORBER FRONT
77
77
80
RUBBER MOUNTING
83
BUSHING
86
BRACKET LEFT
89
BEARING BRACKET SHOCK ABSORBER,BOTTOM
92
SCREW SUPPORT TO FRAME M12X1,5X35,D 127794
92
SCREW BRACKET TO CROSS MEMBER M 12X1.5X40
95
WASHER BEARING BRACKET TO FRAME
98
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
98
NUT STRAP TO SUPPORT
101
SCREW TRAILER COUPLING TO REAR CROSS MEMBER,5 734466
101
SCREW SHOCK ABSORBER TO TOP BRACKET
104
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
104
NUT TRAILER COUPLING TO REAR CROSS MEMBER M 16
107
SCREW BRACKET TO PROPELLER SHAFT BEARING HOUSING M 12X30
107
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
110
LOCK WASHER FITTING TO BRACKET
