Поз.
Артикул
Описание
5
FRONT SPRING 10-LEAF
8
SPRING LEAFNO.1,4 478794
11
BUSHING FRONT
11
BUSHING FRONT
14
SPRING LEAFNO.2,4 478794
17
SPRING LEAFTO 389 320 04 02,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
17
SPRING LEAF , Replaced By: A3953210013
20
SPRING LEAF , Replaced By: A6593210614
20
SPRING LEAFTO 389 320 04 02,5 225134-5 232113 FOR USE WITH 12-LEAF FRONT SPRINGS
23
SPRING LEAFNO.7
23
SPRING LEAF , Replaced By: A3953210015
26
SPRING LEAF , Replaced By: A3953210016
26
SPRING LEAFNO.8
29
SPRING LEAFNO.9
29
SPRING LEAF , Replaced By: A6593210517
32
SPRING LEAFNO.10
35
SPRING LEAF , Replaced By: A6593210519
35
SPRING LEAFNO.11
38
SPRING LEAFNO.12
50
SCREW (SPRING BOLT)
53
NUT PARTICLE FILTER M14
53
NUT , Replaced By: N910113014000
56
SPRING CLAMP SPRING EYE,FRONT,5 533058
59
SCREW FOR SPRING CLAMPS
62
WASHER FOR SPRING CLAMPS
65
SHACKLE FRONT SPRING
68
BUSHING FRONT
68
BUSHING FRONT
71
SHACKLE PIN PARTS KIT
74
SHACKLE PIN PARTS KIT
77
GREASE NIPPLE
80
WASHER AS REQUIRED 4.30 MM
80
WASHER AS REQUIRED 4.00 MM
80
WASHER AS REQUIRED 4.20 MM
83
SEAL RING SPRING SUSPENSION
86
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
89
WASHER , Replaced By: N000125010532
92
NUT EXHAUST PIPE TO SIDE MEMBER
92
NUT , Replaced By: N910113010000
95
PIN , Replaced By: A6573310074
98
RUBBER BUFFER SPRING STOP
101
PLATE FRONT SPRINGS TO FRONT AXLE
101
PLATE RIGHT FRONT SPRING
101
PLATE LEFT FRONT SPRING
104
U-BOLT FRONT SPRINGS TO FRONT AXLE 430 MM
107
SHIM FRONT SPRINGS TO FRONT AXLE
113
WASHER REAR SPRING TO REAR AXLE
116
NUT , Replaced By: N308673020002
