Поз.
Артикул
Описание
5
VALVE 3/2-WAY WABCO
5
VALVE 3/2-WAY VOSS
5
VALVE 3/2-WAY KNORR
5
VALVE 3/2-WAY BOSCH
8
SPRING INSIDE WABCO
11
SEAL RING INSIDE WABCO
14
SEAL RING TOP WABCO
17
SYMBOL PLATE
20
WASHER AT TWO-WAY VALVE
23
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
26
HOLLOW SCREW HEATING CONNECTION
26
HOLLOW SCREW LINE CONNECTION
29
SEAL RING LINE CONNECTION
29
SEAL RING LINE CONNECTION
32
PLASTIC PIPE RISING PIPE 4X6 MM
32
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
35
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
35
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
38
FITTING LINE CONNECTION TO FIRE WALL,5 726664
47
UNION NUT
50
GLAND , Replaced By: A0019901667
53
SLEEVE LEAK LINE
56
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET, NOT USED
59
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
62
LOOM TIE LINE MOUNTING
62
LOOM TIE LINE MOUNTING 280 MM
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
