Поз.
Артикул
Описание
100
PROPELLER SHAFT FROM TRANSMISSION TO TRANSFER CASE 490 MM
115
DRIVE FLANGE
118
UNIVERSAL JOINT CROSS , Replaced By: A9404100031
121
GREASE NIPPLE
124
LOCK AS REQUIRED 2.00 MM
124
LOCK AS REQUIRED 2.20 MM
124
LOCK AS REQUIRED 2.10 MM
130
GREASE NIPPLE
139
SCREW , Replaced By: A3959900501
142
LOCK WASHERROCKINGER TYP 59 G140,59 G150
145
NUT FRONT SPRINGS TO FRONT AXLE
200
PROPELLER SHAFT FROM PROPELLER SHAFT BEARING II TO REAR AXLE 1355 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
215
DRIVE FLANGE
218
UNIVERSAL JOINT CROSS , Replaced By: A9734100031
221
GREASE NIPPLE
224
LOCK AS REQUIRED 1.90 MM
224
LOCK RING AS REQUIRED 1.75 MM
224
LOCK AS REQUIRED 1.70 MM
224
LOCK AS REQUIRED 1.80 MM
224
LOCK AS REQUIRED 1.85 MM
227
SEAL RING PROTECTIVE TUBE 95X14.5 MM
230
GREASE NIPPLE INTERMEDIATE LEVER
239
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
239
SCREW , Replaced By: A3609903001
242
LOCK WASHER FITTING TO BRACKET
245
NUT PROPELLER SHAFT TO REAR AXLES I AND II
502
PROPELLER SHAFT , Replaced By: A6554102902, +002A9404100031
504
PROPELLER SHAFT FROM PROPELLER SHAFT BEARING TO REAR AXLE I 1052 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
515
DRIVE FLANGE
518
UNIVERSAL JOINT CROSS , Replaced By: A9404100031
521
GREASE NIPPLE
524
LOCK AS REQUIRED 2.20 MM
524
LOCK AS REQUIRED 2.00 MM
524
LOCK AS REQUIRED 2.10 MM
527
SEAL RING PROTECTIVE TUBE 102.5X22 MM
527
SEAL RING PROTECTIVE TUBE 105X17 MM
530
GREASE NIPPLE INTERMEDIATE LEVER
539
SCREW PROPELLER SHAFT TO TRANSMISSION
542
LOCK WASHERROCKINGER TYP 59 G140,59 G150
545
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
600
PROPELLER SHAFT FROM TRANSFER CASE TO FRONT AXLE 760 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
615
DRIVE FLANGE
618
UNIVERSAL JOINT , Replaced By: A9424100131
618
UNIVERSAL JOINT CROSS , Replaced By: A0004101628
621
GREASE NIPPLE
624
LOCK AS REQUIRED 2.20 MM
624
LOCK AS REQUIRED 2.00 MM
624
LOCK AS REQUIRED 2.10 MM
627
GASKET PROTECTIVE TUBE
633
SCREW PLUG PROTECTIVE TUBE
639
SCREW PROPELLER SHAFT TO TRANSMISSION
642
LOCK WASHERROCKINGER TYP 59 G140,59 G150
645
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
