Поз.
Артикул
Описание
5
AIR CLEANERULTRAWEB
5
AIR CLEANER
5
AIR CLEANER
52
HEXAGON HEAD BOLT
55
SPACER SLEEVE
58
BUFFERD25X10/M6
61
RUBBER BUSHING EXPANSION TANK D50X45MM
64
SEAL SELF-ADHESIVE ON ONE SIDE 40X30MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
64
SEALING LIP PLASTIC FOAM 20X40MM/1040MM
67
SEAL PLASTIC FOAM 38X45MM/LG1095
70
CLAMP
73
FUEL HOSE. HOSEB5,5-2,5,WEB 629012 13 520122 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
76
CLAMP HOSE TO CAB CONSOLE AND TO ENGINE CONNECTION
76
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
76
CLAMP150-170X12MM
76
CLAMP150-170MM
79
HOSED150/100LG
82
AIR INTAKE PIPED150 MM
82
AIR INTAKE PIPE CASTING 150MM
85
CLAMP150/25MM
88
SCREW BRACKET TO CAB REAR PANEL M 8X20
91
NUTM8
94
HOSED150/130LG
97
WASHER FELT
100
SEAL RING
106
SENDER UNIT. CONTACT SENSOR
109
CONNECTOR
112
PLASTIC PIPE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
115
CONSOLE
118
SENDER UNIT MAINTENANCE INDICATION
121
HEXAGON HEAD BOLT SWITCH TO CAB FLOOR M 5X35
124
NUT RELAY TO BRACKET M5
127
SPACER SLEEVE
130
NUT BRACKET TO FIRE WALL
999
LOOM TIE LINE MOUNTING 150 X 3,6 MM
999
CABLE STRAP7.8X465
