Поз.
Артикул
Описание
32
FINE CONTROL24 V
32
FINE CONTROL , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 314,352387047 401,402,403829142 421,422,423829142 442,443829142 404,424,444017412 407,427,447058665, Replaced By: A0000602698
508
BRACKET
522
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
522
SCREW , Replaced By: N304017008016
522
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
522
SCREW BRACKET TO TAIL LAMP BRACKET
550
SCREW LICENSE PLATE TO BRACKET
564
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
578
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
592
LOCK WASHER BRACKET TO STEERING COLUMN END
606
BEARING TUBE
620
BUSHING MOUNTING
634
HEXAGON HEAD BOLT. SCREW REAR EXHAUST PIPE TO MUFFLER M8 X 110 MM
634
SCREW , Replaced By: N304017008067
634
SCREW BRACKET TO RIGHT SIDE MEMBER,5 434014
648
COVERING
662
SHAFT (CONTROL SHAFT)
676
BALL PIVOT LEVER
676
BALL PIVOT , Replaced By: A3129910120
690
LEVER
704
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
718
NUT BALL PIVOT TO LEVER
732
PULL ROD INJECTION PUMP CONTROL 600 MM
732
PULL ROD
732
PULL ROD , Replaced By: N900331006617
760
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
774
NUT BALL PIVOT TO LEVER
816
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
830
LEVER (CONTROL LEVER),INJECTION PUMP
858
SCREW CLAMP MOUNTING M 6X16
858
SCREW , Replaced By: N914146006102
999
FINE CONTROL12 V
999
FINE CONTROL , Replaced By: A0000602398
999
FINE CONTROL , Replaced By: A0000700371
999
STUD , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009902705
999
BRACKET , Replaced By: A3140180240
999
SEAL RING MODULATION PRESSURE CONTROL
999
BRACKET , Replaced By: A3140100140
999
COVERING , Replaced By: A4073015088
999
PULL ROD
999
LEVER
999
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
NUT SPRING-LOADED PUSH ROD
999
SCREW , Replaced By: N000000001479
