Поз.
Артикул
Описание
182
BRACKET ELECTRIC CABLE TO ENGINE SUPPORT
185
HEXAGON HEAD BOLT MOUNTING, TORSION BAR, ON SIDE MEMBER M14X2X25
188
CLAMP LINES TO BRACKET
188
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
188
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
191
SCREW CLAMP ON BRACKET
191
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
191
SCREW , Replaced By: N304017008018
191
SCREW SUPPORT TO FENDER
194
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
194
HEXAGON NUT BRACKET TO FRAME
194
HEXAGON NUT. NUT , Replaced By: N913023008002
197
BRACKET ELECTRIC CABLE WITH FAN SHROUD TOP LEFT BRACKET TO CRANKCASE
200
SPACER TUBE 3/2-WAY VALVE TO BRACKET,5 556783
203
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
206
SCREW VALVE TO TRANSMISSION CASE COVER
206
SCREW , Replaced By: N304014008018
206
SCREW 3/2-WAY VALVE TO BRACKET
209
BRACKET ELECTRIC CABLE TO ALTERNATOR SUPPORT
209
BRACKET ELECTRIC CABLE TO ALTERNATOR SUPPORT
212
CLAMP OIL DIPSTICK TO RADIATOR
212
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
212
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
212
CLAMP WIRING HARNESS FIXTURE AT AIR COMPRESSOR COOLANT LINE
212
CLAMP LINES TO BRACKET
212
CLAMP DELIVERY AND SUCTION LINES TO FRAME
257
BRACKET
260
SCREW STOP TO BATTERY CASE
263
CLAMPING PIECEM 10
263
CLAMPING PIECEM 12
266
SCREW CABLE CONNECTOR, FROM CHASSIS 818715 ALSO INSTALLED ON:500000-599999
266
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
266
SCREW BOOT TO AIR DUCT AND TO AIR CLEANER
269
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
272
HEXAGON HEAD BOLT. SCREW VALVE TO BRACKET
287
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
290
CABLE SHOE , Replaced By: N046234010006
290
CABLE SHOE , Replaced By: N046234012002
290
CABLE SHOE
290
CABLE SHOE FROM BATTERY MASTER SWITCH TO FRAME
293
GROMMET BATTERY CABLE TO BATTERY MASTER SWITCH
296
NUT ANGLE TO FRAME
296
NUT
299
WASHER , Replaced By: N000433013010
299
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
302
SCREW PLUG RETAINER FOR RPM SENSOR ON WATER PUMP AND CHARGE PRESSURE PIPE
305
CLAMP WIRE CABLE TO SIDE MEMBER AND TO TRANSMISSION
305
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
308
SPACER TUBE BREATHER LINE TO SIDE MEMBER
311
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
311
SCREW , Replaced By: N304017008040
311
SCREW BRACKET TO SIDE MEMBER
311
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
314
WASHER SHIFTING CYLINDER TO CASE
317
ELECTRIC CABLE RUSSET BROWN 16 MM2, ORDER BY THE METER
317
ELECTRIC CABLE , Replaced By: A0005461808
320
CABLE SHOEA 10-35
320
CABLE SHOE. CABLE LUG WITH BORE 10.5 MM X 16 MM2
320
CABLE SHOE BATTERY CABLE
320
CABLE SHOE. CABLE LUGA 10-16
320
CABLE SHOE. CABLE LUG WITH BORE 8.5 MM X 16MM2
323
GROMMET4.0 MM
323
GROMMET BATTERY CABLE TO BATTERY MASTER SWITCH
323
GROMMET HOSE LINE PROTECTION TO 000 546 16 30,71 30
326
ELECTRIC CABLE300 MM, ORDER BY THE METER
329
CABLE SHOEA 6-6
329
CABLE SHOEA 8-6
332
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 4-6 MM2
332
HOUSING , Replaced By: A0025454026
332
FLAT PIN BUSHING , Replaced By: A0035455326
335
PIN BUSHING HOUSING BIPOLAR
338
GROMMET 4-POLE
341
INSULATING HOSE RIGID, FOR CABLE HARNESS DIA.: 26 MM
341
INSULATING HOSE HOSE LINE PROTECTION 10 MM, ORDER BY THE METER
344
CONTROL UNIT OVERLOAD PROTECTOR
347
BUFFER OIL COOLER TO SUBSTRUCTURE,074325
350
NUT BALL PIVOT TO LEVER
353
SPRING WASHER LICENSE PLATE TO BRACKET
359
LOCK PLUG SOCKET
999
BOOT
999
BOOT , Replaced By: A1239971681
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CLAMP
999
SCREW SHOCK ABSORBER TO BOTTOM BRACKET
999
CLAMP
999
LOOM TIE LINE MOUNTING 280 MM
999
SEAL RING CABLE PASSAGE
999
GROMMET ELECTRIC CABLE
999
NUT
999
CABLE GUIDE
999
BRACKET
999
SCREW LOCKING BOLT M8X65,V 208920
999
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
999
BUFFER LEFT, FROM CHASSIS: 010 077937
999
PART NAME MISSING
999
SPACER TUBE OIL-PRESSURE-GAUGE-SENDER-UNIT CABLE, TO BE ADAPTED DURING ASSEMBLY
999
ANGLE
999
BRACKET AT CYLINDER BLOCK, REAR
999
BRACKET ,000022
999
BRACKET BELL HOUSING
999
ANGLE SHIFTING DOME
999
SPACER TUBE , Replaced By: A2089910040
999
COVER
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
BRACKET ELECTRIC CABLE TO OIL COOLER
999
COVER TIMING CASE
999
SCREW
999
COVER
999
GASKET
999
BRACKET INTAKE LINE TO CYLINDER HEAD COVER
999
PROTECTIVE TUBE CONTROL-DEVICE-TO-PLUG-CONNECTION ELECTRIC CABLE
999
PROTECTIVE CAP PROTECTIVE TUBE
999
BRACKET
999
BRACKET LINE MOUNTING
999
GROUND CABLE FROM STARTING MOTOR TERMINAL 31 TO CABLE TERMINAL
999
ELECTRIC CABLE FROM STARTING MOTOR TERMINAL 30 TO CABLE TERMINAL
999
ELECTRIC CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE
999
GROUND CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE
999
ELECTRIC CABLE FROM ALTERNATOR TO PROTECTION AGAINST CONSEQUENTIAL DAMAGE,708903
999
BRACKET ELECTRIC CABLE TO OIL PAN
999
COVER WITH AIR INTAKE. COVER
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
BRACKET FIXTURE ELECTRIC LINE AT WATER PUMP, SIMPLE PART-PLEASE HAVE SHOP MADE
999
WASHER FROM TERMINAL BOX TO CHARGING AIR PIPE
999
BRACKET ELECTRIC CABLE MOUNTING
999
BRACKET ELECTRIC CABLE
999
GROUND CABLE FROM STARTING MOTOR TERMINAL 31 TO CABLE TERMINAL
999
GROUND CABLE FROM STARTING MOTOR TERMINAL 30 TO CABLE TERMINAL
999
GROUND CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE,875390
999
GROUND CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE,875390
999
PROTECTIVE CAP PROTECTIVE TUBE
999
SHIM ELECTRIC CABLE TO CLAMPING PIECE
999
BRACKET AT CYLINDER CRANKCASE
999
BRACKET OIL LINE TO AIR COMPRESSOR, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
THREADED CHUCK RPM SENSOR ON TIMING CASE
999
CLAMPING PIECE CABLE HARNESS MOUNTING
999
FUSE CABLE HARNESS MOUNTING
999
SCREW
999
PLUG CABLE HARNESS MOUNTING
999
PART NAME MISSING. CAP CABLE HARNESS MOUNTING
999
PART NAME MISSING. CAP CABLE HARNESS MOUNTING
999
SCREW BRACKET TO SIDE MEMBER M8X20
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER VIBRATION ABSORBER TO BRACKET
999
CYLINDRICAL HEAD SCREW. SCREW FASTENING CLAMP ON HOLDER
999
END-TYPE TERMINAL
999
SCREW BRAKE SHAFT TO THRUST SHACKLE
999
SCREW RUBBER MOUNTING TO ENGINE M 12X35
999
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
999
SCREW LEVER TO ENGINE CONTROL SHAFT
999
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
999
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
999
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
999
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
999
SCREW , Replaced By: N000000000436
999
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
999
NUT , Replaced By: N913023006001
999
HEXAGON NUT. NUT LINE TO SIDE MEMBER
999
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
999
CLAMP FROM DISTRIBUTOR TO CYLINDER
999
CLAMP LINE TO SIDE MEMBER
999
CLAMP BATTERY CABLE MOUNTING
999
CLAMP ELECTRIC CABLE TO OIL PAN
999
CLAMP OIL LINE TO BRACKET
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
