Поз.
Артикул
Описание
5
SPRING BRACKET REAR AXLE,LEFT AND RIGHT
5
SPRING BRACKET RIGHT
5
SPRING BRACKET LEFT
8
U-BOLT SPRING SUPPORT TO REAR AXLE TUBE
8
U-BOLT SPRING SUPPORT TO REAR AXLE TUBE
11
SLEEVE BOTTOM
14
NUT
14
HEXAGON NUT W COLLARM24X2
14
NUT AIR-SPRING-BELLOWS SUPPORT TO REAR AXLE
50
SPRING SADDLE
53
NUTM24X1.5
53
NUT POWER CYLINDER TO BRACKET
56
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
56
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
59
PLATE
60
MOUNTING PLATE
68
SPRING CASE
71
RUBBER SPRING
74
SCREW CLAMPING BOLT TO ALTERNATOR M 12X1,5X60
77
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
77
NUT BRACKET TO SIDE MEMBER M12X1.5
200
PNEUMATIC SPRING STEERED AXLE LU
200
AIR SPRING
203
PISTON
203
PISTON
206
AIR SPRING BELLOWS
209
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
212
SHOCK ABSORBER REAR AXLE
212
SHOCK ABSORBER REAR AXLE
215
PLATE CENTRAL, ON VEHICLES HAVING NO MERCEDES BENZ BODY FROM IDENT NO. 097836 , 628.000.10.300182, 628.000.14.172141 FOR USE WITH MERCEDES-BENZ BODY FROM IDENT NO. 097976 ALSO INSTALLED ON 300175-300180.
218
PLATE. RETAINER
221
RUBBER MOUNTING , Replaced By: A0003234985
224
RETAINER
227
BUSHING , Replaced By: A0003232750
230
NUT , Replaced By: N913004014005
233
BUSHING , Replaced By: A0003232750
236
SCREWM8X16
236
SCREW GRIP RAIL MOUNTING M 8 X 30
