Поз.
Артикул
Описание
430
RESERVOIR
436
ELBOW FITTING AIR DEHYDRATOR,CONNECTIONS: 1,21
439
NUT AIR RESERVOIR,CONNECTIONS: "14,21,35"
442
THRUST RING CHECK VALVE TO AIR RESERVOIR
442
SEAL RING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTIONS: "1"
445
SEAL RING LINE CONNECTION
448
T-FITTING CYCLONE PRE-FILTER BOWL
451
CONNECTION FITTING LINE CONNECTIONS
454
FITTING (CHECK VALVE) NG12/M22X1.5, FROM IDENT NO. WEB 105309 ALSO INSTALLED ON 104831-104930,104931-105130,105261,105268-105295,105307. EXCEPT 105317,105318,105324,105382,105388. FROM IDENT NO. VF9 300289 ALSO INSTALLED ON 300046,300282-300284.
490
WASHER BRACKET TO CAB REAR PANEL
493
SCREW BRACKET TO SIDE MEMBER M8X20
493
SCREW BRACKET TO CAB REAR PANEL M 8X20
496
HEXALOBULAR BOLT. SCREW , Replaced By: N910105008024
496
SCREW. HEXAGON HEAD BOLT FRONT EXHAUST PIPE TO MUFFLER M8X110 - TO A 979 492 03 40
497
NUT HORN TO BRACKET M8
650
SEPARATOR COMPRESSED AIR DAMPING
652
SOLENOID VALVE
653
REPAIR KIT GASKET KIT
656
REPAIR KIT DRAIN VALVE TO A 005 432 74 01
659
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
999
CLAMP
999
CLAMP
999
CLAMP FRONT AXLE
999
CLAMP FRONT AXLE
999
CLAMP REAR AXLE
999
CLAMP REAR AXLE
