Поз.
Артикул
Описание
410
HOSE AIR-COMPRESSOR AIR INTAKE
415
PIPE BEND ENGINE BREATHING
415
HOSE , Replaced By: A0009977552
430
FITTING AIR COMPRESSOR,CONNECTION: "10"
430
FITTING AT AIR COMPRESSOR
430
PIPE SOCKET AIR COMPRESSOR CYLINDER HEAD
430
FITTING , Replaced By: A4031340156
440
HOSE AIR-COMPRESSOR AIR INTAKE
455
HOSE AIR-COMPRESSOR AIR INTAKE
460
HOSE MOLDED HOSE TO AIR COMPRESSOR
465
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4241340382
465
HOSE FROM INTAKE PIPE TO EXHAUST GAS TURBOCHARGER
470
HOSE AIR-COMPRESSOR AIR INTAKE
475
HOSE AIR-COMPRESSOR AIR INTAKE
485
INTAKE PIPE AIR-COMPRESSOR AIR INTAKE
485
INTAKE PIPE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4241340101
505
CLAMP , Replaced By: A0069970490
505
LOOM TIE , Replaced By: N000000000668
505
LOOM TIE , Replaced By: A0009971590
505
LOOM TIE PIPE ELBOW TO COMPRESSOR
505
LOOM TIE , Replaced By: N916017025000
505
LOOM TIE , Replaced By: N916017040000
505
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
505
CLAMP , Replaced By: N000000000670
505
CLAMP25-40X13 MM
530
HOSE OUTLET FOR AIR COMPRESSOR
535
INTAKE PIPE
535
INTAKE PIPE AIR-COMPRESSOR AIR INTAKE
540
FITTING AIR-COMPRESSOR AIR INTAKE
545
NUT SUCTION LINE TO OIL PUMP
550
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
550
SEAL RING LINE CONNECTION
555
SCREW BRACKET TO CROSS CONNECTION STRUT
555
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
555
SCREW FITTING TO TRANSMISSION M8X32
560
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
565
NUT
570
CLAMP COOLING WATER LINE
570
CLAMP STAY TO BRACKET
570
CLAMP LINES TO BRACKET
575
WASHER EXHAUST MUFFLER TO STRAP
600
SCREW PLUG OIL COOLER,5 360280
600
SCREW PLUGTO 000 553 03 05,000 553 18 05,
600
SCREW PLUG , Replaced By: A0009973532
600
SCREW PLUG FUEL TANK
605
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
605
SEAL RING FROM FUEL TANK TO FUEL TANK
605
SEAL RING INJECTION PUMP
610
CAP
615
SCREW CLAMP ON BRACKET
615
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
620
GASKET COVER TO CYLINDER CRANKCASE
620
GASKET
999
CLAMP , Replaced By: A0069970490
999
SCREWM 8X28
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SPRING WASHER , Replaced By: N000137008212
999
BRACKET
999
BRACKET AIR-COMPRESSOR-TO-CRANKCASE COOLING WATER RETURN LINE
999
LINE FROM CRANKCASE COOLING WATER INLET TO AIR COMPRESSOR
999
HOUSING
999
LINE FROM DISTRIBUTOR TO AIR COMPRESSOR
999
LINE
999
LINE AIR-COMPRESSOR-TO-CRANKCASE COOLING WATER RETURN LINE
999
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
999
GASKET , Replaced By: A4421312080
999
CAP TO PLUG AIR COMPRESSOR OPENING,128243
999
CYLINDER LINER WITH PISTON,AIR-COOLED
999
LINE HORIZONTAL AIR COMPRESSOR TO VERTICAL AIR COMPRESSOR
999
EXPANSION PLUG
999
TIMING CASE
999
LOCKING CAP TO LOCK COOLING WATER BOTTOM OUTLET
999
BRACKET AIR-COMPRESSOR-TO-CRANKCASE COOLING WATER RETURN LINE
999
LINE COOLING WATER INLET FOR AIR COMPRESSOR
999
GASKET
999
GASKET
999
COMPRESSOR
999
HOUSING , Replaced By: A4071300610
999
HOUSING , Replaced By: A4471310215, +001A4471310121, +001A4471310280, +002N000931008210
999
HOUSING , Replaced By: A4071300610, +001A4031301045
999
COMPRESSOR , NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
EXPANSION PLUG
999
BRACKET
999
CRANKSHAFT , Replaced By: A4031300314
999
CRANKSHAFT , Replaced By: A4031300214
999
CRANKSHAFT , 401-403,421-423,440-443,445,446888000 407,427,447062251, Replaced By: A4031311416, +001A4031301645, +001A0001321410
999
GASKET
999
GASKET , Replaced By: A4421310080
999
CONNECTING ROD
999
CYLINDER HEAD , Replaced By: A0001302419, +001A4032002152, +003N000908026001, +003N007603026106
999
CYLINDER HEAD , Replaced By: A0001302419, +001A4032002152, +003N000908026001, +003N007603026106
999
PISTON , Replaced By: A0001302519, +001A4032002152, +003N000908026001, +003N007603026106
999
PISTON , Replaced By: A0001302519, +001A4032002152, +003N000908026001, +003N007603026106
999
CAP
999
SEAL RING , INCLUDED IN GASKET KIT,NO LONGER AVAILABLE INDIVIDUALLY
999
SPRING
999
SEALING COMPOUND TIMING CASE COVER TO TIMING CASE, UP TO ENGINE 978,979 331710 YEAR OF MANUFACTURE 1994
999
SEALANT , Replaced By: A0019892920
999
SEALING COMPOUND TUBE OF SEALANT, WITH REAR CRANKSHAFT SEALING TO BE REWORKED,UP TO ENGINE 283201
999
LOCKING CAP
999
COVERTO 000 460 23 80
999
COVER , Replaced By: A0004666505
999
COVER000 460 24 80/25 80,001 466 06 01
999
SPACER RING PRESSURE DISC TO INTERMEDIATE PLATE
