Поз.
Артикул
Описание
5
PUMP CIRCULATION PUMP 1,U4854
8
COUPLING PARTS KIT
11
CLAMP HOSE TO RETARDER 60-80X13 MM
11
CLAMP
14
SUPPORT
17
20
PIPE LINE RETURN
23
PIPE LINE
26
PIPE LINE38X90MM
29
MOLDED HOSE 90-DEGREE ARC D38
32
MOLDED HOSE FROM HEATING WATER PIPE TO HEATER
35
HOSE ,D 209702
38
HOSE
41
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
47
CLAMP , Replaced By: A3829950701
47
CLAMP LINE MOUNTING
50
SCREW BRACKET AND CLAMP M6X20
53
SCREW , Replaced By: N910143008002
56
NUT BRACKET TO FIRE WALL
59
NUT HORN TO BRACKET M8
