Поз.
Артикул
Описание
43
ENGINE MOUNT
46
ENGINE MOUNT ENGINE SUPPORT TO CRANKCASE, RIGHT
47
SCREW , Replaced By: N000000000436
49
HEXAGON HEAD BOLT SHOCK ABSORBER TO TOP BRACKET M16X1.5X80
90
SUSPENSION EYE REAR
100
SUSPENSION EYE REAR
103
SCREW. HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X35,V 207570
106
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
109
BRACKET REAR
110
SCREW. HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X35,V 207570
113
BRACKET
113
BRACKET , Replaced By: A4711552327
113
BRACKET , Replaced By: A4711501673
116
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
999
BRACKET BRACKET TO ENGINE SUPPORT
