Поз.
Артикул
Описание
73
FLANGED MANIFOLD FUEL LINE AT METERING UNIT OUTLET
73
FLANGED MANIFOLD FUEL LINE AT METERING UNIT OUTLET, USE UP OLD PART NUMBER UP TO ENGINE S0214040, Replaced By: A4711441444
78
NUT END PIECE TO EXHAUST PIPE
122
BRACKET METERING UNIT AT CYLINDER CRANKCASE
124
BUSHING METERING UNIT AT CYLINDER CRANKCASE
126
ELASTOMER BEARING METERING UNIT AT CYLINDER CRANKCASE
130
SCREW CLAMP ON BRACKET
140
METERING UNIT DOSER BLOCK ASSEMBLY, REMAN PART - WHEN YOU ORDER THIS PART PLEASE ADD THE PREFIX"R" IN FRONT OF THE PART NO. THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE
150
HEXAGON HEAD BOLT SHIFT LEVER TO CAB FLOOR M 8X45
160
INJECTION VALVE FUEL DOSER VALVE, REMAN PART - WHEN YOU ORDER THIS PART PLEASE ADD THE PREFIX"R" IN FRONT OF THE PART NO.
162
INJECTION VALVE FUEL DOSER VALVE
165
GASKET
170
HEXAGON HEAD BOLT INJECTION VALVE AT EXHAUST LINE M8X50MM - 10.9
180
FUEL LINE METERING UNIT TO INJECTION VALVE
190
BANJO BOLTA8
200
SEALING RING AT PRESSURE REGULATOR
213
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
213
SCREW STOP TO BATTERY CASE
216
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
225
COOLANT LINE RETURN
230
COOLANT LINE FEED
235
BRACKET FUEL LINE TO CRANKCASE
235
BRACKET FUEL LINE TO CRANKCASE, Replaced By: A4720781341
238
BRACKET , Replaced By: A4720781441
238
BRACKET
242
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
244
SCREW CLAMP ON BRACKET
246
HEXAGON NUT. NUT , Replaced By: N913023008002
248
SCREWM 10X20
290
BANJO BOLT TRANSMISSION VENTILATION,225250
300
SEALING RING TEST CONNECTION
310
FITTING
310
SCREW-IN FITTING
320
SEALING RING TEST CONNECTION
999
RS SERVOMOTOR
999
RS SERVOMOTOR
