Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
FITTING , Replaced By: A0029905971
8
FITTING (PARTS KIT),LINE RUPTURE
10
UNION NUT
15
GLAND , Replaced By: A0019901667
15
SEAL CONE
20
BANJO UNION , Replaced By: N915052004006
20
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
25
SLEEVE LEAK LINE
180
HOLLOW SCREW HEATING CONNECTION
185
SEAL RING LINE CONNECTION
190
VALVE (SOLENOID VALVE) HERION
190
VALVE (SOLENOID VALVE) WABCO
190
VALVE (SOLENOID VALVE) HERION
192
VALVE (3/2-WAY SOLENOID VALVE) KNORR
192
VALVE (3/2-WAY SOLENOID VALVE) EKS
192
VALVE (3/2-WAY SOLENOID VALVE) WABCO
192
VALVE (SOLENOID VALVE)
192
VALVE , Replaced By: A0049975736
194
REPAIR KIT , Replaced By: A0012608357
194
REPAIR KITTO 001 997 34 36,002 997 58 36,
195
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
196
BRACKET SOLENOID VALVE
197
SCREW AT SIDE MEMBER,REAR M 8X135
198
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
198
NUT , Replaced By: N913004008001
199
SCREW TO PLUG THE FREE CONNECTIONS
200
SEAL RINGBOSCH
201
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
201
SCREW PLUG , Replaced By: N000908012009
202
SEAL RING VALVE TO VALVE
203
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
203
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
204
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
205
SEAL RING LINE CONNECTION
210
HOLLOW SCREW HEATING CONNECTION
210
HOLLOW SCREW LINE CONNECTION
215
SCREW VALVE TO BRACKET M 8X55
215
SCREW , Replaced By: N304017008043
220
NUT , Replaced By: N913004008001
220
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
REPAIR KITTO 000 430 48 26,KNORR
999
PROTECTIVE CAPWABCO
999
SPRING
999
PISTON
999
LOOM TIE LINE MOUNTING 280 MM
999
GASKET KITKNORR
999
VALVE , Replaced By: A0049975736
999
SEAL RINGWABCO
999
BALL PIVOT LEVER
999
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
999
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
999
ELECTRIC CABLE FROM CAB PLUG CONNECTION TO SOLENOID VALVE,4 784736
999
BUSHING"WABCO"
999
BEARING BRACKET REVERSING LEVER
999
SHAFT REVERSING LEVER
999
LEVER POWER CYLINDER TO CONTROL LEVER
999
LEVER REVERSING LEVER
999
BUSHING POWER CYLINDER TO CONTROL LEVER
999
PIPE ELBOW
999
PIPE ELBOW (OIL FILLER PIPE)
999
SHAFT REVERSING LEVER
999
LEVER (FOLLOWER LEVER)
999
ROD LOAD SENSOR CONTROL
999
COTTER PIN CYLINDER TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER
999
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
999
SCREW DISTRIBUTOR TO CAB
999
NUT BALL PIVOT TO LEVER
999
NUT L.H. THREAD
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
SCREW PLUGROCKINGER,TYP 59 U150
999
BALL PIVOT , Replaced By: A3129910120
