Поз.
Артикул
Описание
580
CONSOLE PEDESTAL
584
STRUT BUMPER,LEFT
584
STRUT BUMPER,RIGHT
588
SCREW SUPPORT TO SIDE MEMBER M 14X45
588
SCREW , Replaced By: N308676014012
590
SCREW , Replaced By: A9429901304
590
SCREW APPARATUS SUPPORT TO FRAME
592
NUT , Replaced By: N910113014000
592
NUT STEERING SUPPORT TO FRAME
596
MOUNTING CAB,LEFT
596
MOUNTING RIGHT SIDE MEMBER
596
MOUNTING , Replaced By: A6558910420
596
MOUNTING , Replaced By: A6558910320
600
SHIM MOUNTING TO CONSOLE
604
SCREW , Replaced By: N308676014008
604
SCREW MOUNTING TO CONSOLE M 14X35
608
SCREW MOUNTING TO CONSOLE M 14X55
612
WASHER SPARE WHEEL CARRIER
616
NUT , Replaced By: N910113014000
616
NUT STEERING SUPPORT TO FRAME
620
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
672
WASHER BEARING BRACKET
680
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
684
NUT COMBINATION CYLINDER TO BEARING BRACKET
684
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
688
MOUNTING CAB,LEFT
688
MOUNTING CAB, RIGHT
692
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
692
SCREW , Replaced By: N308676012011
692
SCREW , Replaced By: N308676012031
696
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
700
SCREW BRACKET TO CAB CONSOLE,K 035197
700
SCREW , Replaced By: N000961014064
700
SCREW BRACKET TO SIDE MEMBER
708
LOCK WASHER FITTING TO BRACKET
712
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
716
WASHER BRACKET TO SIDE MEMBER,5 703114
716
WASHER , Replaced By: N000125015019
716
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
720
NUT , Replaced By: N910113014001
720
NUT BRACKET TO SIDE MEMBER
999
MOUNTING CAB SUSPENSION,REAR
999
MOUNTING , Replaced By: A3878910072
999
SHIM CAB TO FRAME
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
