Поз.
Артикул
Описание
11
ANTINOISE CAPSULE RIGHT
11
ANTINOISE CAPSULE RIGHT
11
ANTINOISE CAPSULE LEFT
11
ANTINOISE CAPSULE LEFT
12
BRACKET ENGINE COVERING
12
BRACKET ENGINE COVERING
27
SCREW CLAMP TO BRACKET AND TO PIPE
31
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
43
BRACKET COVER PLATE
47
BRACKET COVER PLATE
47
BRACKET COVERING TO CAB
103
SCREW CONSOLE TO SIDE MEMBER
103
SCREW BRACKET TO SIDE MEMBER
107
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
107
SCREW , Replaced By: N308676012012
111
NUT , Replaced By: N910113014001
111
NUT SUPPORT TO SIDE MEMBER
111
NUT BRACKET TO SIDE MEMBER
123
FLOOR PLATE COVERING
123
FLOOR PLATE COVERING
131
SCREW , Replaced By: N304017006034
131
SCREW COVER PLATE TO COVER PLATE M 6 X 10
135
WASHER COMPRESSED AIR LINE TO BRACKET
135
WASHER , Replaced By: N009021006208
139
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
142
BRACKET ENGINE COVERING,4 921288
144
SCREW , Replaced By: N304017008034
146
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
148
WASHER EXHAUST MUFFLER TO STRAP
148
WASHER , Replaced By: N000125008443
999
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
