Поз.
Артикул
Описание
6
FRONT SPRING 11-LEAF
6
FRONT SPRING 10-LEAF
6
FRONT SPRING 8-LEAF
6
FRONT SPRING 11-LEAF
6
FRONT SPRING 13-LEAF
6
FRONT SPRING 11-LEAF
6
FRONT SPRING 8-LEAF
6
FRONT SPRING 13-LEAF,4 883986
6
FRONT SPRING 8-LEAF
6
FRONT SPRING 13-LEAF
6
FRONT SPRING 10-LEAF
6
FRONT SPRING 13-LEAF
6
FRONT SPRING 7-LEAF
6
FRONT SPRING ,4 884299 ONLY REPLACEABLE BY PAIRS, Replaced By: A6173200702
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1,4 883986
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1,4 884299
12
SPRING LEAFNO.1
12
SPRING LEAFNO.1,4 669737
18
BUSHING
18
BUSHING
24
SPRING LEAFNO.2
24
SPRING LEAFNO.2,4 883986
24
SPRING LEAFNO.2
24
SPRING LEAF ,4 669736, Replaced By: A3833201294, +001A3833212012
24
SPRING LEAFNO.2,4 669737
24
SPRING LEAFNO.2,4 669737
24
SPRING LEAFNO.2
24
SPRING LEAFNO.2
24
SPRING LEAFNO.2
24
SPRING LEAFNO.2
24
SPRING LEAFNO.2
24
SPRING LEAFNO.2,4 884299
30
SPRING LEAFNO.3,4 8119265 184441
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3,4 884299
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3,4 883986
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3
30
SPRING LEAFNO.3,5 184442
30
SPRING LEAFNO.3
36
SPRING CLAMP , Replaced By: A6173210333
36
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY
36
SPRING CLAMP , Replaced By: A6173210333
36
SPRING CLAMP ,5 940410
42
RIVET SPRING CLAMP TO SPRING LEAF
48
SPRING LEAFNO.4,4 883986
48
SPRING LEAFNO.4
48
SPRING LEAFNO.4
48
SPRING LEAFNO.4
48
SPRING LEAFNO.2
48
SPRING LEAFNO.4
48
SPRING LEAFNO.4
48
SPRING LEAFNO.4,5 184441
48
SPRING LEAFNO.4
48
SPRING LEAFNO.4
48
SPRING LEAFNO.4,4 884299
48
SPRING LEAF , Replaced By: A3853203494
48
SPRING LEAF , Replaced By: A3833212212
48
SPRING LEAFNO.4
52
SPRING CLAMP , Replaced By: A6173210333
52
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY
52
SPRING CLAMP , Replaced By: A6173210333
52
SPRING CLAMP ,5 940410
54
RIVET SPRING CLAMP TO SPRING LEAF
58
SPRING LEAFNO.5
60
SPRING LEAFNO.6
62
SPRING LEAFNO.7
64
SPRING LEAFNO.8
66
SPRING LEAFNO.9
68
SPRING LEAFNO.10
70
SPRING CLAMP ,5 940410
70
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY
70
SPRING CLAMP , Replaced By: A6173210333
70
SPRING CLAMP , Replaced By: A6173210333
70
SPRING CLAMP ,4 811925, Replaced By: A3123240633
72
SPRING CLAMP AT SPRING LEAF NO.4
74
RIVET SPRING CLAMP TO SPRING LEAF
78
SPACER TUBE SPRING CLAMP
84
SPACER TUBE SPRING CLAMP TO SPRING LEAF,5 484790
84
SPACER TUBE , Replaced By: A0003213253
90
SCREW , Replaced By: N308765012007
90
SCREW FOR SPRING CLAMPS,5 484789
94
SCREW 3/2-WAY VALVE TO BRACKET
94
SCREW , Replaced By: N304014008009
96
SCREW SPRING CLAMP
100
WASHER FOR SPRING CLAMPS
102
NUT SUPPORT TO SIDE MEMBER
108
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
108
NUT , Replaced By: N913004008001
110
SHIM BETWEEN SPRING AND PLATE 19 MM
110
SHIM
110
SHIM
110
SHIM ,4 883986
110
SHIM
112
SPACER
114
SPRING BOLT
114
SPRING BOLT
114
SPRING BOLTM12X160, TO 682 320 73 02, 74 02
114
SPRING BOLT ,5 711071
114
SPRING BOLT
114
SPRING BOLT
120
NUT , Replaced By: N910113012005
120
HEXAGON NUT. NUT SPRING BOLT
