Поз.
Артикул
Описание
375
HOSE FROM RADIATOR TO THERMOSTAT
384
CLAMP HOSE 70-90X13 MM
384
CLAMP , Replaced By: N000000000674
405
CLAMP HOSE 70-90X13 MM
405
CLAMP , Replaced By: N000000000674
411
CONNECTOR AT WATER PUMP
417
GASKET CONNECTOR, Replaced By: A0002011080
417
GASKET , Replaced By: A4422010480
423
SCREW BRACKET TO SIDE MEMBER
429
SPRING WASHER STEERING COLUMN BRACKET TO CAB
435
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
435
HOSE ,5 071491, Replaced By: A6175012782, +001A6175001072, +001A6175060235
441
CLAMP
441
CLAMP , Replaced By: N000000000670
447
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
447
CLAMP , Replaced By: N000000000667
457
FLANGE ENGINE BREATHING
459
GASKET. SEAL DE-AERATION PIPE TO ENGINE
465
SCREW END PIECE TO EXHAUST PIPE M 10X25
471
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
496
FLANGE
496
FLANGE , Replaced By: A6205060261
503
HOSE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
507
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
507
CLAMP , Replaced By: N000000000667
513
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR
513
HOSE ,5 071491, Replaced By: A6175060235, +001A6175001072, +001A6175012782
519
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
519
CLAMP , Replaced By: N000000000667
525
LINE HEATING AND BREATHING,5 0714925 077722
525
LINE ,5 071491, Replaced By: A6175001072, +001A6175012782, +001A6175060235
531
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
537
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
537
CLAMP , Replaced By: N000000000667
603
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
609
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
609
CLAMP , Replaced By: N916017011001
999
RADIATOR , Replaced By: A0015010801
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
CLAMP FEED LINE TO THERMOSTAT
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
HOSE FROM FLANGE TO HEATING PIPE
999
LINE HEATING AND BREATHING
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER , Replaced By: N000137008204
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N000933008337
999
SCREW , Replaced By: N304017008018
999
SCREW , Replaced By: A0099900101
999
SCREW SUPPORT TO FENDER
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
GASKET HEATING PIPE TO ENGINE
