Поз.
Артикул
Описание
131
BRACKET SPARE WHEEL CARRIER
131
BRACKET SPARE WHEEL CARRIER
131
BRACKET , Replaced By: A3874001639
131
BRACKET SPARE WHEEL CARRIER,4 179002-4 369654
131
BRACKET , FROM CHASSIS 4 369655-4 613856, Replaced By: A3874003939, +004N000934020001, +004N007349021000, +004N912004020100
131
BRACKET SPARE WHEEL CARRIER,4 613857
133
BRACKET , Replaced By: A3874001739
133
BRACKET SPARE WHEEL CARRIER,4 179002-4 369654
133
BRACKET , Replaced By: A3874001739
133
BRACKET SPARE WHEEL CARRIER,4 179002-4 369654
133
BRACKET , FROM CHASSIS 4 369655-4 613856, Replaced By: A3874004039, +004N000934020001, +004N007349021000, +004N912004020100
133
BRACKET SPARE WHEEL CARRIER,4 613857
135
PIN AT BRACKET
135
PIN ,4 179002-4 369654
135
PIN AT BRACKET
137
SCREW , Replaced By: A6519900023
137
SCREW SPARE WHEEL CARRIER TO SIDE MEMBER
137
EYEBOLT ,4 179002-4 369654
137
EYEBOLT , FROM CHASSIS 4 369655-4 613856
137
SCREW SPARE WHEEL CARRIER TO SIDE MEMBER
141
LOCK WASHERROCKINGER TYP 59 G140,59 G150
141
LOCK WASHERROCKINGER TYP 59 G140,59 G150
141
LOCK WASHERROCKINGER TYP 59 G140,59 G150
143
NUT , Replaced By: N308673016001
143
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
143
NUT ,4 179002-4 369654
143
NUT ,4 179002-4 369654
143
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
145
WASHER ,4 179002-4 369654
147
BASE BLOCK SPARE WHEEL CARRIER TO SIDE MEMBER
147
BASE BLOCK SPARE WHEEL CARRIER TO SIDE MEMBER
148
COTTER PINROCKINGER TYP 260 G140
148
COTTER PINROCKINGER TYP 260 G140
148
COTTER PINROCKINGER TYP 260 G140
149
CLAMPING SLEEVE BRACKET TO PEDAL BEARING BRACKET
149
CLAMPING SLEEVE BRACKET TO PEDAL BEARING BRACKET
151
BRACKET ,4 179002-4 369654
151
BRACKET , FROM CHASSIS 4 369655-4 613856, Replaced By: A3874004139, +004N000934020001, +004N007349021000, +004N912004020100
151
BRACKET SPARE WHEEL CARRIER
153
BRACKET SPARE WHEEL CARRIER,4 179002-4 369654
153
BRACKET , FROM CHASSIS 4 369655-4 613856, Replaced By: A3874004239, +004N000934020001, +004N007349021000, +004N912004020100
153
BRACKET , Replaced By: A3874001739
153
BRACKET SPARE WHEEL CARRIER,4 179002-4 369654
155
SUPPORT SPARE WHEEL HOIST
157
RIVET12X58 MM, TO BE ADAPTED DURING ASSEMBLY
159
SCREW , Replaced By: N308676012026
159
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
159
SCREW END PIECE TO EXHAUST PIPE M 10X25
159
SCREW , Replaced By: N304017010002
159
SCREW BRACKET TO SIDE MEMBER
161
NUT SUPPORT TO SIDE MEMBER
161
NUT , Replaced By: N910113010000
161
NUT STRAP TO BRACKET
163
BRACKET SPARE WHEEL CARRIER
163
SUPPORT SPARE WHEEL HOIST,4 179002
163
SUPPORT SPARE WHEEL HOIST,4 179002
165
SPARE WHEEL HOIST
165
SPARE WHEEL HOIST , Replaced By: A3834000639
165
BRACKET , Replaced By: A3834000639
167
WORM ,5 127459, Replaced By: A6204030085, +001A6204030683
167
WORM
167
WORM ,5 127459, Replaced By: A6204030085, +001A6204030683
169
BUSHING
169
BUSHING
171
STOP GEAR ,5 127459, Replaced By: A6204030383, +001A6204030085
171
STOP GEAR ,5 127460
171
STOP GEAR ,5 127459, Replaced By: A6204030383, +001A6204030085
173
CLAMPING SLEEVE CRANK TO BUSHING
173
CLAMPING SLEEVE CRANK TO BUSHING
175
WIRE CABLE. ROPE , ORDER BY THE METER, Replaced By: N083334008000
175
WIRE CABLE
175
CABLE , Replaced By: N083331008500
175
WIRE CABLE
177
COVERING PROTECTION PLATE TO BRACKET
177
COVERING PROTECTION PLATE TO BRACKET
179
SCREW COVER PLATE TO BRACKET
179
SCREW COVER PLATE TO BRACKET
181
WASHER , Replaced By: N009021006208
181
WASHER COMPRESSED AIR LINE TO BRACKET
181
WASHER COMPRESSED AIR LINE TO BRACKET
183
NUT , Replaced By: N913004006001
183
NUT PUMP TO BRACKET
183
NUT PUMP TO BRACKET
185
WASHER WORM AND SHAFT TO BRACKET
185
WASHER WORM AND SHAFT TO BRACKET
187
WASHER WORM AND SHAFT TO BRACKET
187
WASHER WORM AND SHAFT TO BRACKET
189
CLAMPING SLEEVE , Replaced By: N308752008000
189
CLAMPING PIN BRACKET TO SUPPORT
189
CLAMPING PIN BRACKET TO SUPPORT
191
DISC SPRING WORM AND SHAFT TO BRACKET
191
DISC SPRING WORM AND SHAFT TO BRACKET
193
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
193
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
195
NUT , Replaced By: N910113010000
195
NUT STRAP TO BRACKET
195
NUT STRAP TO BRACKET
197
BUSHING SPARE WHEEL HOIST,4 179002
197
BUSHING CRANK
199
CRANK SPARE WHEEL HOIST
199
CRANK , Replaced By: A3814030045
199
CRANK SPARE WHEEL HOIST
201
CLAMPING SLEEVE CRANK TO BUSHING
203
CLAMPING BRACKET SPARE WHEEL HOIST
205
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
207
WASHER SPARE WHEEL TO BRACKET
207
NUT STRAP TO BRACKET
207
NUT , Replaced By: N910113010000
209
WASHER SPARE WHEEL TO BRACKET
209
WASHER TORSION BAR TO BEARING BRACKET
209
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
211
LOCK WASHER SPARE WHEEL TO BRACKET
211
LOCK WASHERROCKINGER TYP 59 G140,59 G150
211
LOCK WASHER SPARE WHEEL TO BRACKET
213
NUT REAR SPRING TO REAR AXLE
213
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
213
NUT , Replaced By: N308673016001
213
NUT REAR SPRING TO REAR AXLE
213
NUT , Replaced By: N308674020000
213
NUT , Replaced By: N308673020002
225
RIVET12X58 MM, TO BE ADAPTED DURING ASSEMBLY
225
RIVET REAR CROSS MEMBER 12X42 MM
227
SOCKET WRENCH27X32
999
ROD , Replaced By: A0005832545
999
ROD , FROM IDENT NO. 4 368902 ALSO INSTALLED ON 361336,365889,366416,368062,368229,368497,368500,368502,368515,368584-368587,368655-368662,368802, 368827,368828,368833,368838,368839,368844,368846,368848,368850-368855,368859,368864,368867,368868, 368870,368876,368879,368880,368887,368889,368892-368894,368896-368898,369294.
999
BRACKET , NO LONGER AVAILABLE
999
TURN HANDLE , Replaced By: A4355810003
999
CLAMPING PIECE SPARE WHEEL TO SUPPORT
999
STOP RIGHT,4 179001
999
SHIM COMPRESSED AIR LINE TO ENGINE
