Поз.
Артикул
Описание
5
STEERING SUPPORT AT FRAME
5
STEERING SUPPORT AT FRAME
5
STEERING SUPPORT STEERING TO FRAME
5
STEERING SUPPORT STEERING TO FRAME
8
SCREW STEERING SUPPORT TO FRAME
8
SCREW STEERING SUPPORT TO FRAME M 14X55
8
SCREW STEERING SUPPORT TO FRAME M 14X50
11
NUT CONSOLE TO SUPPORT
11
NUT STEERING SUPPORT TO FRAME
11
NUT , Replaced By: N910113016001
14
FITTED SCREW , Replaced By: N000609020017
14
FITTED SCREW STEERING BRACKET TO FRAME
14
SCREW BRACKET TO REAR AXLE M 20X1.5X45
17
PITMAN ARM AT STEERING GEAR
23
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I,5 946137
23
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I,5 946137
23
DRAG LINKLEMFOERDER
23
DRAG LINKEHRENREICH
29
DRAG LINK ENDEHRENREICH
29
DRAG LINK END R.H. THREAD EHRENREICH
29
BALL JOINT L.H. THREAD TRW
29
DRAG LINK END , Replaced By: A0014602348, +001A0019905451
29
DRAG LINK END , Replaced By: A0014602248
29
DRAG LINK END , Replaced By: A0014602348
29
DRAG LINK END , Replaced By: A0014607648
29
DRAG LINK END , Replaced By: A0014607748
29
DRAG LINK END , Replaced By: A0014607848
29
DRAG LINK END L.H. THREAD TRW, Replaced By: A0024600348
35
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
35
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
35
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
38
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
38
SCREW , Replaced By: N308676012017
41
NUT , Replaced By: N910113012003
41
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
44
NUT DRAG LINK TO LEVER
44
NUT DRAG LINK END M 24X1.5
47
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
50
DRAG LINK FROM PITMAN ARM TO INTERMEDIATE LEVER EHRENREICH, COMPONENT PARTS NOT AVAILABLE
50
DRAG LINK FROM PITMAN ARM TO INTERMEDIATE LEVER LEMFOERDER, COMPONENT PARTS NOT AVAILABLE
53
BOOT
56
NUT DRAG LINK TO LEVER
59
COTTER PIN DRAG LINK TO LEVER
62
STEERING SUPPORT INTERMEDIATE LEVER I
65
SCREW SUPPORTING ARM TO BELL HOUSING
65
SCREW BRACKET TO SIDE MEMBER
65
SCREW , Replaced By: N308676018001
68
NUT TORSION BAR TO BEARING BRACKET,5 904661
71
STEERING INTERMEDIATE ARMI
71
STEERING INTERMEDIATE ARMI
76
GREASE NIPPLE
76
GREASE NIPPLE , Replaced By: N071412008102
77
SPACER TUBE INSIDE
80
NEEDLE BEARING INSIDE AND OUTSIDE
80
NEEDLE BEARING , Replaced By: A0219814710
80
NEEDLE BEARING INSIDE AND OUTSIDE
83
SEAL RING INSIDE
86
THRUST WASHER INSIDE
89
THRUST WASHER OUTSIDE
92
CAP STEERING SUPPORT
95
NUT FRONT SPRING TO SPRING BRACKET
95
NUT SHOCK ABSORBER TO FRONT SPRING, Replaced By: N910113022000
95
NUT , Replaced By: N910113022001
98
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II EHRENREICH, COMPONENT PARTS NOT AVAILABLE
98
DRAG LINK FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II LEMFOERDER, COMPONENT PARTS NOT AVAILABLE
101
BOOT
104
NUT DRAG LINK TO LEVER
107
COTTER PIN DRAG LINK TO LEVER
999
BLEEDER VALVE , Replaced By: A0004205155
999
DRAG LINK END , Replaced By: A0014600848
999
DRAG LINK END , Replaced By: A0014601248, +001A0019905451
999
DRAG LINK END , Replaced By: A0014601448, +001A0019905451
999
DRAG LINK END , Replaced By: A0014601648, +002A0019907651
999
BOOT DRAG LINK
999
GUIDE PISTON ROD GUIDE
999
CYLINDER , Replaced By: A0004662192
999
WASHER
999
SEAL RING PISTON ROD GUIDE
999
WASHER PISTON ROD GUIDE
999
SEAL RING PISTON ROD GUIDE
999
SEAL RING PISTON
999
PISTON PISTON ROD GUIDE
999
PISTON PISTON ROD GUIDE
999
PISTON CYLINDER
999
DRAG LINK END , Replaced By: A0014601748
999
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I LEMFOERDER, 1 PIECE REQUIRED IN ADDITION: A 001 460 06 48 TO BE ADAPTED DURING ASSEMBLY
999
DRAG LINK FROM PITMAN ARM TO FRONT AXLE I EHRENREICH
999
DRAG LINK END , Replaced By: A0014602248
999
NUT CYLINDER
999
LOCK PISTON ROD GUIDE
999
LOCK PISTON ROD GUIDE
999
LOCK PISTON ROD GUIDE
999
SEAL RING PISTON ROD GUIDE
999
SEAL RING , Replaced By: A0189976748
999
SEAL RING PISTON ROD GUIDE
999
SEAL RING PISTON
999
SEAL RING PISTON ROD GUIDE
999
DRAG LINK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 749282, Replaced By: A0004604005
999
DRAG LINK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 749282, Replaced By: A0004604105
999
DRAG LINK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 756071, Replaced By: A0004605405
999
DRAG LINK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 756071, Replaced By: A0004605505
