Поз.
Артикул
Описание
8
RUBBER MOUNTING FRONT
8
RUBBER MOUNTING FRONT
8
RUBBER MOUNTING FRONT
8
RUBBER MOUNTING , Replaced By: A6582410013
8
RUBBER MOUNTING , Replaced By: A6582410113
8
RUBBER MOUNTING , Replaced By: A6582410213
14
SCREW BRACKET TO FRAME M 16X45
14
SCREW BRACKET TO SUPPORT
17
SCREW CONSOLE TO FRAME SIDE MEMBER M16X38
20
WASHER CONSOLE TO FRAME
41
ENGINE SUPPORT , Replaced By: A6552423101
41
ENGINE SUPPORT , Replaced By: A6552423201
41
ENGINE SUPPORT , Replaced By: A6202421601
41
ENGINE SUPPORT , Replaced By: A6202421701
41
ENGINE SUPPORT REAR RIGHT
41
ENGINE SUPPORT REAR LEFT
44
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 22X1.5X65
44
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 22X1.5X70
44
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 22X1.5X95
50
RUBBER MOUNTING REAR
50
RUBBER MOUNTING
50
RUBBER MOUNTING
50
RUBBER MOUNTING REAR
50
RUBBER MOUNTING
50
RUBBER MOUNTING REAR
53
SCREENING PLATE
53
SCREENING PLATE REAR RUBBER MOUNTING
56
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X80
56
SCREW ENGINE MOUNTING AND BRACKET TO BELL HOUSING SUPPORTING ARM M 18X80
56
SCREW , Replaced By: A0039909304
59
WASHER CONSOLE TO FRAME
59
WASHER ENGINE MOUNTING TO SUPPORTING ARM
65
CONSOLE ENGINE REAR MOUNTING
71
SCREW CONSOLE TO FRAME
71
SCREW , Replaced By: N308676016020
71
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X38
71
SCREW BRACKET TO SIDE MEMBER
71
SCREW BEARING BRACKET TO SIDE MEMBER
74
NUT COMBINATION CYLINDER TO BEARING BRACKET
74
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
80
SCREW , Replaced By: N308676014003
80
SCREW CONSOLE TO SIDE MEMBER
80
HEXAGON HEAD BOLT. SCREW ENGINE MOUNTING TO SUPPORT,ON CLUTCH END M 14X30
83
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
83
WASHER
