Поз.
Артикул
Описание
8
BEARING BRACKET
8
CONSOLE ,5 9107605 910761, Replaced By: A6223230163, +001N000939014036
11
STUD BOLT ,5 910760
17
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
17
SCREW RIGHT FRONT RUBBER MOUNTING M16X1,5X50
23
NUT COMBINATION CYLINDER TO BEARING BRACKET
23
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
26
TORSION BAR
32
LINK TORSION BAR TO CONSOLE
35
BUSHING LINK TO CONSOLE, INAPPLICABLE TO IDENT NO.: 5 545417,5 545468,5 549721,5 549753,5 551382,5 553458,5 556586,5 556951,5 557200,5 568184,5 568795,5 575157,5 575986.K 054776
38
SPACER WASHER LINK TO CONSOLE
44
NUT BRACKET TO SIDE MEMBER
44
NUT , Replaced By: N910113014001
45
SCREW GUSSET PLATE TO CROSS MEMBER
47
RUBBER MOUNTING SHACKLE TO TORSION BAR
50
LOCK RING SHACKLE TO TORSION BAR
53
BRACKET TORSION BAR
56
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
59
NUT SUPPORT TO SIDE MEMBER
62
REPAIR KIT TORSION BAR TO LINK
65
BUSHING TORSION BAR TO BEARING BRACKET
68
SPACER WASHER LINK TO CONSOLE
68
WASHER TORSION BAR TO BEARING BRACKET
68
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
71
NUT CONSOLE TO SUPPORT
74
SHOCK ABSORBER FRONT AXLE
74
SHOCK ABSORBER , Replaced By: A0063230900
74
SHOCK ABSORBER , Replaced By: A0063230900
77
BUSHINGTO 004 323 52 00
77
SPACER RINGTO 002 323 86 00,003 323 03 00,
80
RUBBER MOUNTINGTO 003 326 46 00
80
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
80
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
80
RUBBER BUFFER , Replaced By: A0003233144
83
SCREW ,5 587352, Replaced By: N308765016016
83
HEXAGON HEAD BOLT PISTON TO AIR-SPRING-BELLOWS SUPPORT,5 587352
86
SCREW SHOCK ABSORBER TO TOP BRACKET
87
SPACER TUBE SHOCK ABSORBER TO BRACKET
88
SPACER TUBE TRAILER COUPLING TO REAR CROSS MEMBER
92
NUT COMBINATION CYLINDER TO BEARING BRACKET
92
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
