Поз.
Артикул
Описание
32
FLEXIBLE METAL TUBE FRONT LEFT
35
COLLAR (SLIDING COLLAR)
38
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
41
SCREW SUPPORT TO FENDER
41
SCREW , Replaced By: N304017008018
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
44
NUT , Replaced By: N913004008001
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
47
EXHAUST PIPE FRONT,REAR LEFT PART,5 904457
47
EXHAUST PIPE LEFT,5 597837
47
EXHAUST PIPE RIGHT FRONT
47
EXHAUST PIPE FROM RIGHT CONNECTOR TO MUFFLER
47
EXHAUST PIPE LEFT FRONT
68
BRACKET FRONT EXHAUST PIPE,RIGHT
68
BRACKET FRONT EXHAUST PIPE,LEFT
80
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER
86
CLAMP EXHAUST PIPE TO BRACKET
92
SCREW EXHAUST PIPE TO BRACKET
101
NUT STRAP TO BRACKET
101
NUT , Replaced By: N910113010000
107
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
110
SCREW , Replaced By: N304017010002
110
SCREW BRACKET TO SIDE MEMBER
113
NUT STRAP TO BRACKET
113
NUT , Replaced By: N910113010000
116
EXHAUST MUFFLER ,5 535800
116
EXHAUST MUFFLER
128
CONSOLE REAR EXHAUST MUFFLER 200 MM
131
CONSOLE REAR EXHAUST MUFFLER 178 MM
158
SCREW CONSOLE TO SIDE MEMBER
158
SCREW , Replaced By: N308676012026
158
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
161
WASHER LEAF SPRING TO STRUT
167
NUT SUPPORT TO SIDE MEMBER
173
BRACKET EXHAUST MUFFLER SUSPENSION
176
BRACKET EXHAUST MUFFLER
188
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
194
NUT , Replaced By: N910113010000
194
NUT STRAP TO BRACKET
197
STRAP EXHAUST MUFFLER TO BRACKET
233
SCREW STRAP TO BRACKET
239
NUT , Replaced By: N910113010000
239
NUT STRAP TO BRACKET
245
SCREW EXHAUST MUFFLER TO STRAP
248
WASHER , Replaced By: N000125008443
248
WASHER EXHAUST MUFFLER TO STRAP
251
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
251
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
251
NUT , Replaced By: N913004008001
254
REAR EXHAUST PIPE , Replaced By: A6554922914
254
END PIECE
275
END PIECE
275
REAR EXHAUST PIPE , Replaced By: A6554922914
275
REAR EXHAUST PIPE , Replaced By: A6254921904
281
CLAMP EXHAUST PIPE TO BRACKET
290
SCREW REAR EXHAUST PIPE TO MUFFLER
293
NUT STRAP TO BRACKET
293
NUT , Replaced By: N910113010000
320
CLAMP EXHAUST PIPE TO BRACKET
323
SCREW BRACKET TO SIDE MEMBER
323
SCREW , Replaced By: N304017010002
326
NUT , Replaced By: N910113010000
326
NUT STRAP TO BRACKET
329
BRACKET TAIL PIPE
332
SCREW END PIECE TO EXHAUST PIPE M 10X25
335
NUT , Replaced By: N910113010000
335
NUT STRAP TO BRACKET
999
SPACER TUBE EXHAUST PIPE TO PROTECTIVE PLATE
