Поз.
Артикул
Описание
8
FLANGE LEFT
8
CONNECTOR LEFT FRONT
8
INTERMEDIATE PIECE RIGHT
8
INTERMEDIATE PIECE LEFT
8
CONNECTOR , Replaced By: A6254900925
8
INTERMEDIATE PIECE LEFT
16
INTERMEDIATE PIECE LEFT
24
INTERMEDIATE PIECE RIGHT
24
CONNECTOR RIGHT FRONT
24
CONNECTOR , Replaced By: A6254900725
32
FLANGE RIGHT
56
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
64
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD
72
HEX. NUT M 10 AGGN 14 440. NUT CONNECTING PIPE TO EXHAUST MANIFOLD
72
NUT CONNECTOR TO EXHAUST MANIFOLD
72
NUT END PIECE TO EXHAUST PIPE
80
THROTTLE HOUSING LEFT
80
THROTTLE HOUSING , Replaced By: A4421404953
80
THROTTLE HOUSING , Replaced By: A4421404853
96
THROTTLE HOUSING LEFT
96
THROTTLE HOUSING RIGHT
96
THROTTLE HOUSING RIGHT
168
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
168
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
168
CYLINDER , Replaced By: A0004305926
170
BUSHING"WABCO"
192
BRACKET EXHAUST-BRAKE POWER CYLINDER
200
PIN POWER CYLINDER TO BRACKET
208
WASHER INTERMEDIATE SPEED STOP
216
NUT POWER CYLINDER TO BRACKET
232
NUT CONNECTING PIPE TO EXHAUST BRAKE
240
CONNECTOR LEFT
248
INTERMEDIATE PIECE THROTTLE HOUSING,LEFT
248
EXHAUST PIPE LEFT
248
EXHAUST PIPE FRONT
256
CONNECTOR RIGHT
264
EXHAUST PIPE RIGHT
264
EXHAUST PIPE THROTTLE HOUSING,RIGHT
272
SCREENING PLATE SCREENING PLATE TO TURBOCHARGER
280
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE FRONT PART TO REAR PART
280
FLEXIBLE METAL TUBE FRONT LEFT
288
COLLAR (SLIDING COLLAR)
288
COLLAR FRONT EXHAUST PIPE FRONT PART TO REAR PART
296
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
296
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
304
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
304
SCREW , Replaced By: N304017008028
312
NUT , Replaced By: N913004008001
312
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
320
BRACKET FRONT EXHAUST PIPE,RIGHT
320
BRACKET FRONT EXHAUST PIPE,LEFT
328
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE FROM SLIDING PIECE TO EXHAUST MUFFLER, LEFT
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT
328
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT
328
INTERMEDIATE PIECE EXHAUST MUFFLER,LEFT
328
INTERMEDIATE PIECE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT
328
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT AND RIGHT
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT
328
EXHAUST PIPE FRONT EXHAUST PIPE FRONT PART TO REAR PART
328
EXHAUST PIPE EXHAUST MUFFLER,LEFT
328
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
328
EXHAUST PIPE FROM SLIDING PIECE TO EXHAUST MUFFLER, RIGHT
336
BRACKET FRONT EXHAUST PIPE
344
BRACKET RIGHT EXHAUST PIPE
352
CLAMP EXHAUST PIPE TO BRACKET
360
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
368
SCREW BRACKET TO SIDE MEMBER
368
SCREW , Replaced By: N304017010002
376
NUT , Replaced By: N910113010000
376
NUT STRAP TO BRACKET
440
PROTECTIVE PLATE LOWER EXHAUST PIPE
442
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
444
BRACKET
448
CLAMP STEERING OIL TANK
448
CLAMP REAR EXHAUST PIPE TO BRACKET
722
COVERING EXHAUST PIPE
724
PROTECTIVE PLATE (HEAT SHIELD)
726
BRACKET HEAT SHIELD MOUNTING
792
PROTECTIVE PLATE FUEL TANK
792
PROTECTIVE PLATE (HEAT SHIELD)
800
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
800
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
800
CLAMP , Replaced By: N071555090502
800
CLAMP , Replaced By: N071555100501
808
SCREW , Replaced By: N304017010002
808
SCREW BRACKET TO SIDE MEMBER
816
NUT STRAP TO BRACKET
816
NUT , Replaced By: N910113010000
999
REPAIR KIT POWER CYLINDER TO 000 430 60 26
