Поз.
Артикул
Описание
5
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
5
GROMMET LINE THRU FRAME
8
WASHER BRACKET TO LEFT SIDE MEMBER
11
BRACKET RIGHT COMPRESSED AIR LINES
11
BRACKET LEFT COMPRESSED AIR LINES
11
BRACKET RIGHT COMPRESSED AIR LINES
11
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554303310
11
BRACKET RIGHT COMPRESSED AIR LINES, Replaced By: A6554303410
17
SCREW , Replaced By: N304017008021
17
SCREW PIPE CLAMP
18
WASHER , Replaced By: N000125008443
18
WASHER EXHAUST MUFFLER TO STRAP
20
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
20
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
20
NUT , Replaced By: N913004008001
23
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
23
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
29
SCREW BRACKET TO CROSS CONNECTION STRUT
29
SCREW , Replaced By: N304017008034
35
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
35
NUT , Replaced By: N913004008001
35
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
41
BRACKET BREATHER LINE TO SIDE MEMBER
47
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
47
SCREW , Replaced By: N304017008027
53
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
53
NUT , Replaced By: N913004008001
53
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
59
BRACKET LINE MOUNTING
59
BRACKET COMPRESSED AIR LINE TO LEFT SIDE MEMBER, Replaced By: A3184280240
62
BRACKET COMPRESSED AIR LINE TO LEFT SIDE MEMBER, NOT USED
62
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
68
SCREW , Replaced By: N304017008027
68
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
72
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
76
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
76
NUT , Replaced By: N913004008001
76
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
78
NUT , Replaced By: N910113014001
78
NUT BRACKET TO SIDE MEMBER
80
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
81
BRACKET LINE TO FRONT PANEL
82
NUT BRACKET TO PIN
83
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
83
WASHER , Replaced By: N009021005205
86
BRACKET , Replaced By: A6205243040
86
BRACKET BRACKET TO CROSS MEMBER
89
SCREW , Replaced By: N304017008027
89
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
92
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
92
NUT , Replaced By: N913004008001
92
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
95
BRACKET FUEL LINE TO BELL HOUSING
98
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
101
NUT STRAP TO BRACKET
101
NUT , Replaced By: N910113010000
104
BRACKET BRACKET TO CONTROL ARM
107
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
221
LOOM TIE LINE MOUNTING
221
LOOM TIE LINE MOUNTING 280 MM
