Поз.
Артикул
Описание
5
BRACKET LINE MOUNTING
8
BRACKET LINE MOUNTING
11
BRACKET LINE MOUNTING
12
SUPPORT LINE MOUNTING
13
BRACKET BEHIND FRONT AXLE
14
BRACKET
14
BRACKET RIGHT BRAKE HOSE
14
BRACKET
14
BRACKET BRAKE HOSE
15
BRACKET RIGHT BRAKE HOSE
15
BRACKET LEFT
16
BRACKET
17
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 18/15 MM
17
CLAMP SENSOR CABLE TO FRONT AXLE
17
CLAMP LINE MOUNTING 15-18 MM,V 207570
17
CLAMP BRAKE HOSE BRACKET
17
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
17
CLAMP PIPE LINE TO CONDENSER
17
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
17
CLAMP HOSE TO FLANGE AND TO VALVE
17
CLAMP , Replaced By: A3829950101
17
CLAMP MOUNTING USED FOR COMPRESSED AIR LINES 18/15, Replaced By: A0019951142
17
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
17
CLAMP LINE MOUNTING
17
CLAMP BREATHER LINE TO BRACKET
17
CLAMP MOUNTING USED FOR COMPRESSED AIR LINES 18/20
17
CLAMP DELIVERY AND SUCTION LINES TO FRAME
17
CLAMP COMPRESSED AIR LINE TO TRANSMISSION COVER 25/15
17
CLAMP SAFETY VALVE AT BRACKET
17
CLAMP OIL DIPSTICK TO RADIATOR
20
SCREW BRACKET TO CAB REAR PANEL M 8X20
20
SCREW BATTERY CABLE TO BRACKET M6X45
20
SCREWM 8X90
20
HEXALOBULAR BOLT LINE MOUNTING M6 X 25
20
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
20
SCREW , Replaced By: N910143008002
20
SCREW , Replaced By: N910143008000
20
SCREW GUSSET PLATE TO CROSS MEMBER M16 X 1.5 X 40
20
SCREW SPEED SENSOR TO REAR AXLE
20
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
20
SCREW CLAMP MOUNTING M 6X16
23
WASHER , Replaced By: N009021006208
26
NUT HORN TO BRACKET M8
26
NUT BRACKET TO FIRE WALL
26
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
33
LOOM TIE LINE MOUNTING
33
CABLE TIE. LOOM TIE1140 X 8.9 MM
35
LOOM TIE HOSE TO RADIATOR AND TO EXPANSION TANK
35
CLAMP HOSE TO FITTING 11 - 20 MM
35
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
62
QUICK-RELEASE COUPLING. COUPLING DISTRIBUTOR,CONNECTION: "11,12,21,23", TO VOSS 232, FROM IDENT NO. WEB 105309 ALSO INSTALLED ON 104831-104930,104931-105130,105261,105268-105295,105307. EXCEPT 105317,105318,105324,105382,105388. FROM IDENT NO. VF9 300289 ALSO INSTALLED ON 300046,300282-300284.
62
COUPLING DISTRIBUTOR,CONNECTION: "11,21,23", UP TO IDENT NO. WEB 105308 EXCEPT FOR 104831-104930,104931-105130,105261,105268-105295,105307. ALSO INSTALLED IN 105317,105318,105324,105382,105388. UP TO IDENT NO.VF9 300288 EXCEPT FOR 300046,300282-300284.
65
NUT ELECTRONIC ACCELERATOR PEDAL
68
WASHER BRACKET MOUNTING
87
MUFFLER , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.08.2009
87
MUFFLER , Replaced By: A6284300570
87
MUFFLER , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.07.2009
88
PLATE
89
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
89
TEST CONNECTION
89
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
89
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
89
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
99
BRACKET REFILLING CONNECTION ENGINE COMPARTMENT
122
NUT BRACKET TO SIDE MEMBER
122
NUT BULKHEAD FITTING TO BRACKET
