Поз.
Артикул
Описание
98
101
COMPRESSED AIR HOSE FROM HOSE TO MUFFLER
101
BRAKE HOSE FROM HOSE TO MUFFLER, Replaced By: A0014292635
104
107
110
113
116
LINE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 30.04.2008
119
122
PLASTIC PIPE RISING PIPE 4X6 MM
125
LINE
128
CONNECTION FITTING LINE CONNECTIONS
128
CONNECTION FITTING , Replaced By: N003902018002
131
FITTING , Replaced By: A0039979072
131
FITTING , Replaced By: A0029906071
131
TS DOUBLE FITTING SOLENOID VALVE
134
SEAL RING LINE CONNECTION
137
SCREW-IN FITTING , Replaced By: A0029970271
137
SCREW-IN FITTING AIR COMPRESSOR,CONNECTION: "20"
140
THRUST RING SUCTION LINE TO OIL PUMP
143
SEAL RING LINE CONNECTION
146
HEXALOBULAR BOLT LINE MOUNTING M6 X 25
146
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
149
CLAMP LINE MOUNTING 15-18 MM,V 207570
149
CLAMP6/15, Replaced By: N000000007509
149
CLAMP SENSOR CABLE TO FRONT AXLE
149
CLAMP LINE MOUNTING
149
CLAMP BRAKE HOSE BRACKET
149
CLAMP PIPE LINE TO CONDENSER
149
CLAMP MOUNTING USED FOR COMPRESSED AIR LINES 6/15
149
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 18/15 MM
149
CLAMP MOUNTING USED FOR COMPRESSED AIR LINES 18/15, Replaced By: A0019951142
149
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
152
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
152
NUT BRACKET TO FIRE WALL
155
MUFFLER , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.07.2009
155
MUFFLER , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.08.2009
158
SCREW BRACKET TO SIDE MEMBER M8X20
158
SCREW BRACKET TO CAB REAR PANEL M 8X20
161
NUT HORN TO BRACKET M8
161
NUT ENGINE MOUNTING M8
164
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
167
WASHER P.T.O. TO TRANSMISSION
170
BRACKET
173
BRACKET
176
VALVE (3/2-WAY SOLENOID VALVE)
179
REPAIR KIT 3/2-WAY SOLENOID VALVE
182
SCREW 3/2-WAY VALVE TO BRACKET
182
SCREW. HEXAGON HEAD BOLT GGVS-COMPONENT IN BATTERY CARRIER M8X55
185
NUT HORN TO BRACKET M8
185
NUT ENGINE MOUNTING M8
188
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
191
VALVE
194
CLAMP32/20MM, Replaced By: N000000007538
194
CLAMP
197
LINE
200
LOOM TIE
999
HEXAGON HEAD BOLT. SCREW RUBBER BUFFER TO SUPPORT M 12X90
