Поз.
Артикул
Описание
355
MOUNTING REAR SWIVEL BAR,TOP
360
JOINT BEARING FRONT SWIVEL BAR,TOP
362
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION 4.8X13
370
BRACKET
390
MOUNTING , NO.7365 INO.5856 INO.7327 IIII
395
PIN LEFT DOOR
400
COVERING RIGHT DOOR, NO.7327 INO.5856 IIIII
415
TUBE
420
PLATE3 MM
420
PLATE2MM
500
CONTROL BAR FRONT, NO.7365 INO.5856 INO.7327 IIII
501
CONTROL BAR REAR, NO.7365 INO.5856 INO.7327 IIII
505
BALL JOINT
510
SEAL RING
515
SELF-ALGN.ROLLER BEARING
520
LOCK
525
ANGLE , NO.7365 INO.5856 INO.7327 IIII
528
COVERING , NO.7365 INO.5856 INO.7327 IIII
530
SUPPORTING ARM TOP, NO.7365 INO.5856 INO.7327 IIII
535
MOUNTING
540
BUFFER
540
STOP , Replaced By: A0009887011
545
PLUG
550
HOSE1M, ORDER BY THE METER
555
MOUNTING
560
JOINT BEARING FRONT SWIVEL BAR,TOP
565
BRACKET RIGHT
567
BRACKET LEFT
570
BRACKET RIGHT
575
DOOR CYLINDER RIGHT
577
DOOR CYLINDER
580
MOUNTING
585
POTENTIOMETER SWIVEL BAR,TOP
590
MOUNTING , I WHEN ORDERING,ADDITIONALLY STATE COLOR NUMBER: AEROGREYI ITURQUOISE BLUEII IIII
595
PIN LEFT DOOR
600
COVERING RIGHT DOOR, NO.7327 INO.5856 IIIII
605
ANGLE , NO.7327 INO.5856 IIIII
607
ANGLE , NO.7327 INO.5856 IIIII
610
STEERING LINKAGE
720
SCREWM 8 X 16
723
SCREW FRAME MOUNTING M 6X25
732
SCREWM5X12
