Поз.
Артикул
Описание
5
BRACKET
10
BRACKET PANELLING 4098 MM, TO BE ADAPTED DURING ASSEMBLY
15
BRACKET PANELLING 2800 MM, TO BE ADAPTED DURING ASSEMBLY
30
PLATE
35
ATTACHMENT ANGLE BRACKET700MM
35
ATTACHMENT ANGLE BRACKET IN FRONT OF FRONT AXLE,RIGHT
35
ATTACHMENT ANGLE BRACKET BEHIND FRONT AXLE,RIGHT
35
35
ANGLE BEHIND FRONT AXLE,RIGHT
37
ATTACHMENT ANGLE BRACKET700MM
38
ATTACHMENT ANGLE BRACKET500X25X20MM
39
ATTACHMENT ANGLE BRACKET BEHIND FRONT AXLE,LEFT 242MM
45
FRAME FRONT LEFT 15 X 25 X 44 MM
62
BRACKET AIR RESERVOIR
65
BRACKET AIR RESERVOIR
68
80
RAILL 4695 MM
80
RAILL2598 MM
85
SCREWM6X16
90
NUTM6
95
RIVETED NUTM 6X1.0
98
CONNECTION LEFT 2950X30X1MM, TO BE ADAPTED DURING ASSEMBLY
98
CONNECTION2220X30X1MM, TO BE ADAPTED DURING ASSEMBLY
